Print Quality Problems (continued)
Symptom Possible Causes
Print quality is Media may be slipping against the
poor. (continued) platen roller causing the printing to
compress.
The printer skips The label format extends beyond the
labels randomly or label length.
sends an
intermittent error.
Continuous The label mark sensor is not in the
empty/pause fault correct position.
light (yellow LED).
If your printer is not receiving downloaded data, try the solutions in the accompanying
table.
Symptom Possible Causes
Printer does not Serial port is incorrectly configured.
communicate with
the host.
Damaged or incorrect I/O cable.
Several problems can cause data loss or communication problems on the printer. Data
loss can result in printing errors or missing field data.
Your printer is a serial ASCII device. It communicates with the host through an ASCII
serial communication I/O port. Hardware handshaking involves the use of a hardware
wire. Software handshaking involves a two-way datalink between the devices. The two
devices communicate with each other without losing data through the use of
handshaking. The printer sends both forms of handshaking simultaneously when the
printer's input buffer is full. Any loss of data can cause printing errors.
NugFont
HelvC
Solution
Switch to approved media or clean the printhead and
platen roller as described in Chapter 3, "Maintaining
the Printer."
Edit the format to ensure that the text fits on the
label.
Properly position the label mark sensor. For help, see
"Adjusting the Label Mark Sensor" in Chapter 5.
Solution
Make sure the printer's serial port settings match those
of the host. Print a software test configuration label as
described in Chapter 1 to check the serial port
settings.
Check the connections at both ends or replace the
cable. See Appendix C for cable information.
