Setting the AXlink Device Number

The 8-position device DIP switch defines the AXP-CPI16 as an AXlink device. It can be one of 255
devices in the Axcess Control System. Set the device number with the total value of all ON (down)
positions. As an example, the device DIP switch shown below defines device number 129 (1+128=129).
AMX standard device numbers are assigned as follows:
1. Strip 0.25 inch of wire insulation off all wires.
2. Insert each wire into the appropriate opening on the connector according to the wiring diagrams and
connector types described in this section.
3. Tighten the screws to secure the wires. Do not tighten the screws excessively; doing so may strip the
threads and damage the connector.

Connecting the Two 20-pin Headers

The following chart notes the pinouts of the two 20-pin headers for P2 and P3.
AXP-CPI16 P2/P3 Pinouts
P2
Pin Function Pin Function Pin Function Pin Function
1 Output 1
2 Output 2
3 Output 3
4 Output 4
5 Output 5
6 Output 6
7 Output 7
8 Output 8
9 GND
10 PWR
Pin 10 provides +12 VDC power from AXlink bus. Add 1K series resistors when using AXP-CPI16 with
LED indicators receiving 12 VDC power from Pin 10.
4
Position 1 2 3 4 5 6
Value 1 2 4 8 16 32 64 128
Cards are 1 through 25.
Boxes are 96 through 127.
Panels are 128 through 255.
P3
11 GND 1
12 GND 2
13 Input 1 3
14 Input 2 4
15 Input 3 5
16 Input 4 6
17 Input 5 7
18 Input 6 8
19 Input 7 9
20 Input 8 10
7 8
OFF
OFF
ON 1 2 3 4 5 6 7 8
ON
Output 9 11 GND
Output 10 12 GND
Output 11 13 Input 9
Output 12 14 Input 10
Output 13 15 Input 11
Output 14 16 Input 12
Output 15 17 Input 13
Output 16 18 Input 14
GND 19 Input 15
PWR 20 Input 16
AXP-CPI16 16-Channel Custom Panel Interface
