AMX TPI-PRO-2 Datasheet

Modero Touch Panels
®
Total Presentation Interface -
Pro Edition
Demonstrate, review, mark up and illustrate. The Total Presentation Interface – Pro Edition (TPI-PRO)
takes presentations to a whole new level. Now, multiple video and RGB sources can be simultaneously
delivered to a display, and then managed via a connected touch monitor or NetLinx Controller. Whether
using the Interface in the classroom as an electronic blackboard or in the courtroom to display and
annotate evidence – the TPI-PRO conveniently supports an array of professional needs.
HIGH RESOLUTION INPUTS & OUTPUTS
The TPI-PRO is available in two models to support two (TPI-PRO-2) or four (TPI-PRO-4) high resolution video and/
or RGB inputs. Both models include two high resolution outputs as well. Input/output resolutions up to 1920 x 1200
pixels are supported.
LIVE NOTES AND ANNOTATION
Live notes and annotation are easily overlaid and the combined image can be output in real time to video displays
and projectors.
• Available in 2 or 4 video/RGB inputs (both versions have 2 video/RGB outputs)
• Up to 4 video or RGB windows can be simultaneously displayed and controlled
• Inputs can be scaled to fit into independent windows or viewed full-screen
• USB wired and wireless mouse pass-through allows the presenter to view and control up to four computers
from one display
• Slim, one rack height for easy rack or flush mounting on a table or podium
T P I - P R O - 2 / T P I - P R O - 4 D ATA S H E E T
