Operation/Reference Guide
AXP-CPI16
16-Channel Custom Panel Interface
D o c u m e n t I D : 0 3 8 - 0 0 4 - 1 3 3 4
C u s t o m P a n e l I n t e r f a c e s
L a s t R e v i s e d : 8 / 1 6 / 2 0 0 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXP-CPI16 CUSTOM PANEL INTERFACE BOARD (16 BUTTONS) and is the answer not in the manual?

Questions and answers

Summary of Contents for AMX AXP-CPI16 CUSTOM PANEL INTERFACE BOARD (16 BUTTONS)

  • Page 1 Operation/Reference Guide AXP-CPI16 16-Channel Custom Panel Interface D o c u m e n t I D : 0 3 8 - 0 0 4 - 1 3 3 4 C u s t o m P a n e l I n t e r f a c e s L a s t R e v i s e d : 8 / 1 6 / 2 0 0 6...
  • Page 2 RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Dealer for a third party.
  • Page 3: Table Of Contents

    Table of Contents Table of Contents Product Information ...................1 Specifications......................1 Installation ......................5 Mounting Dimensions ....................5 Setting the AXlink Device Number ................6 Preparing/connecting captive wires ................6 Connecting the Two 20-pin Headers ................ 6 Switch Wiring Diagrams.................... 7 Connecting the AXlink Wiring...................
  • Page 4 Table of Contents AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 5: Product Information

    Product Information Product Information The AMX AXP-CPI16 16 Channel Custom Panel Interface Board (FIG. 1) simplifies the process of creating custom control panels for Axcess systems. Providing contact closure inputs and feedback outputs for up to 16 buttons, the miniature PC board contains a 20-pin header for ribbon cable installation or for direct mounting to a printed circuit board.
  • Page 6 Product Information AXP-CPI16 Specifications (Cont.) AXlink Status LED Indicates AXlink communication status as follows: • One blink per second communication is functioning. • Two blinks per second devices specified in the master program do not match the specified devices found. •...
  • Page 7 Product Information 1 2 3 4 5 6 7 8 AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 8 Product Information AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 9: Installation

    Installation Installation Mounting Dimensions AXlink AXlink AXM GND PWR AXM Top View (Component Side) Top View (Component Side) 19 20 19 20 FIG. 1 AXP-CPI16 mounting dimensions Mounting Dimensions Item Inch Item Description 0.10 2.50 P2 20-Pin Header .025 inch (6 mm) square pins, .1 inch (2.4 mm) typical spacing 1.75 44.50 L...
  • Page 10: Setting The Axlink Device Number

    Value 1 2 4 8 16 32 64 128 1 2 3 4 5 6 7 8 AMX standard device numbers are assigned as follows: Cards are 1 through 25. Boxes are 96 through 127. Panels are 128 through 255.
  • Page 11: Switch Wiring Diagrams

    Installation Switch Wiring Diagrams FIG. 2 diagrams LED and Switch wiring. LED Wiring (Typical) Switch Wiring (Typical) SW 1 LED 1 SW 2 LED 2 SW 3 LED 3 FIG. 2 LED and switch wiring diagrams Connecting the AXlink Wiring To install the AXlink data/power bus wiring.
  • Page 12 Installation AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 13: Programming

    Programming Programming Use the same Axcess commands as with other AXlink control panels, such as the AXU-MSP series mini-softwire panels. When using the AXP-CPI16 as a control device, use On, Off, and Pulse commands to control sources connected to outputs and Push and Release commands to receive inputs. For additional information, refer to the Axcess Programming Language instruction manual.
  • Page 14: Testing The Unit

    Programming Testing the Unit If you have programmed the Axcess software, load the program into a PC connected to the control system Master port. See Programming on page 4. 1. Push switches connected to the AXP-CPI16. 2. Look at the lower left of the Axcess screen to verify that the correct device and channel numbers are displayed.
  • Page 15: Axp-Cpi16 System Worksheet

    AXP-CPI16 System Worksheet AXP-CPI16 System Worksheet Dealer ID Date Dealer PO Number SO Number Description Serial Number Rev Number Device Number HEADER P2 20-PIN HEADER FUNCTION Channel +12 VDC PWR Pin Number Pin Number AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 16 AXP-CPI16 System Worksheet HEADER P3 Channel 20-PIN HEADER FUNCTION +12 VDC PWR Pin Number Pin Number AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 17 System Worksheet AXP-CPI16 16-Channel Custom Panel Interface...
  • Page 18 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
