ASSEMBLY INSTRUCTIONS

CCPM/SHAFT DRIVE
www.vigorpilot.com
™
Designed by Curtis Youngblood in
conjunction with JR Engineers
VIGOR CS SPECIFICATIONS
Overall Length
Overall Height
Main Rotor Blade Length
(Main rotor blades not included)
Tail Rotor Diameter
Gear Ratio
Gross Weight
®
56.25"
18"
680 – 720 mm
10.34"
9.33:1:4.83
10.2–10.5 lb
JRP9051.46
Revised 7/2001
