Save Show

Notice the cursor flashing over the 1
character (A-Z, 0-9) using the +/- key and move to
the next digit with the > key.
Press F3 to Confirm when done.
If no show name is entered before pressing confirm,
the console will automatically assign an available
show name as "show xx" between show01 –
show30. The number can still be changed if not
used already.
Press F3 to Confirm.
The save show will now start and the display will
indicate the process during save.
After the show is successfully saved, the display will
return to the normal screen.
Note: Up to 30 shows can be stored on a 32M compact flash card.
Please delete unneeded show files before saving if the CF card is full.
Load show
Notice the cursor flashing over the 1
the <> key to select the wanted show and press
F3 to Confirm.
Notice the cursor flashing over the 1 for All. Press
the right arrow key or press F2 key to next page to
select either load all, patch and setting, scene or
effect, then press F3 to Confirm.
Note: Load scene will load all submaster's contents including effects on subs.
Strand 200 Console Manual
st
x, enter a
st
show, use
Save show name
As: xxxxxx
Esc <+/->
No show name !
Assign as:
Show XX
Esc <+/->
Processing
▊▊▊▊▊▊▊▊▊▊
xx %
"Show name"
Load show
01.SHOW01
02.SHOW02
Esc Confirm
Load SHOW01
3. All
4. Patch & setting
Esc Next Confirm
Load SHOW01
1. Scene
2. Effect
Esc Next Confirm
Confirm
Confirm
