Dipless Manual Crossfade; Time Fades - Strand Lighting 200 Console Operation Manual

Dipless Manual Crossfade

The reverse configuration of the preset B master allows the operator to have both faders set
in the up position (A will be at 100%, B will be at 0%) and move them at the same time in the
same direction physically while the light levels from both presets move in the opposite
direction.
Note: Remember, there must be levels in faders that are controlled by BOTH preset masters for the
dipless manual crossfade to function properly.

Time Fades

Smooth timed crossfades can be achieved by setting the time fade faders.
The left fader is for all levels that are going up (or fading in) and the right
fader is for all levels going down (or fading out). (i.e. If the operator is
crossfading out of preset A and into preset B, then the in fader will affect the
time of preset B coming in while the out fader will affect the time of preset A
going out).
Page 16 Strand 200 Console Manual
