Unpatch A Dimmer; Proportional Patch; Display Patch - Strand Lighting 200 Console Operation Manual

Other acceptable commands are...
Key Command
+ 1 + 2 @ 5 *
Thru 1 > 5 @ 3 *
- 1 > 5 – 4 @ 3 *

Unpatch a Dimmer

Acceptable commands are...
1 @ *
1 @ 0 *
Thru 1 > 512 @ *
Note: Press clear to delete previous entry.

Proportional Patch

Proportional patching will patch a dimmer (output) at any level from zero to full.
Command
1 @ 1 @ 50
Dimmer one's maximum level is now 50%.
Note: The proportionally patched dimmer output will not rise above proportioned level.
Continue entering all necessary patch information.

Display Patch

This will display all current patch information.
Notice the cursor flashing over the 1 for edit patch.
Press the right arrow key to access display patch
then press F3 to Confirm.
Channel: 01
Dim:001
LL: FL
Esc
The right arrow key will allow the user to step through the patch by channel in numerical
order.
Strand 200 Console Manual
Description
Patches dimmers (output) 1 and 2 to channel 5.
Patches dimmer (output) 1 through 5 to channel 3.
Patches dimmer (output) 1, 2, 3 and 5 to channel 3.
Unpatches dimmer 1.
Unpatches dimmer 1.
Unpatches all dimmers.
Description
Patches dimmer (output) 1 to channel 1 at a maximum level of 50%
Display patch will start by showing channel one and it's
dimmer (output) assignment. The screen at the left
shows the default patch information.
1. Edit patch
2. Display patch
3. Default patch
Esc Next Confirm
Page 33
