DMX Output – accepts a DMX512 5 pin XLR connector from the dimmers or any other DMX
device.
Audio Input – allows a fader to control the audio trigger threshold from an audio source
connected to the console.
MIDI Input – allows an external source to control the triggering of effects from the console.
(MIDI stands for Musical Instrument Digital Interface)
MIDI Thru – allows the in-line connection of the console from one MIDI source to another.
Power Connector – accepts the power adaptor from the power transformer.
Console Power Switch – rocker switch to turn power to the console on and off.
Compact Flash Slot – allows for saving of shows onto a compact flash card. Only a 32M
compact flash card can be used. The compact flash card has to be dedicated to the 200
console. It cannot share with other devices due to a different file format. The show file
cannot be read on a standard PC.
Video Display Card (optional) – allows for the addition of a video display card for a display
monitor.

Terminology Notes

It is easy to confuse the terms of scenes and submasters. The following information will help
clarify...
Submasters – faders that contain cues or looks that are played back manually.
Scenes – faders that contain cues or looks that are played back via the playback faders. All
levels recorded into scenes will be controlled by the submaster of the same number.
Strand 200 Console Manual Page 11
