BP7485 Southtowne CF4900
12/4/13
10:15 AM
Page 1
READ AND SAVE THESE INSTRUCTIONS
™
SOUTHTOWNE
54" Ceiling Fan Owner's Manual
Model Numbers
CF4900BS00
CF4900ORB00
Brushed Steel
Oil Rubbed Bronze
CF4900VS00
Vintage Steel
??.?
Net Weight:
Lbs.
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
Part No. F40BP74850000
Form No. BP7485
www.emersonfans.com
Revision: 131201
U.L. Model No.: CF4900

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOUTHTOWNE CF4900BS00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson SOUTHTOWNE CF4900BS00

Summary of Contents for Emerson SOUTHTOWNE CF4900BS00

  • Page 1 Oil Rubbed Bronze CF4900VS00 Vintage Steel ??.? Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 Part No. F40BP74850000 Form No. BP7485 www.emersonfans.com Revision: 131201...

  • Page 2: Table Of Contents

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson could Additional Safety Instructions for Installation result in personal injury or property damage.

  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or Fan Blades Flanges accessories not designated for use with this product Hanger Bracket by Emerson Electric Co. could result in personal injury Hanger Ball/4.5” Downrod Assembly or property damage. 50-Watt Halogen Bulbs RCK55 Receiver...

  • Page 4: Electrical Requirements

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 4 1. Unpacking Instructions (continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly Remove and discard the cardboard shipping retainer One Phillips head screwdriver One stepladder securing the motor hub in the motor housing assembly.

  • Page 5: Ceiling Fan Assembly

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 5 3. Ceiling Fan Assembly #10-32 x 14" WASHER Position the fan blade on top of the blade flange by HEAD BLADE SCREWS aligning the three raised bosses into the blade mounting (3 per blade assembly) holes.

  • Page 6: Warning

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 6 3. Ceiling Fan Assembly (continued) Remove the hanger ball by loosening the setscrew in HANGER BALL the hanger ball until the ball falls freely down the downrod (Figure 4). Remove the pin from the downrod, then remove the hanger ball.

  • Page 7: Warning

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 7 3. Ceiling Fan Assembly (continued) Screw two #8-32 x 1-1/4” threaded studs (provided) into the motor (Figure 7). #8-32 x 1-1/4" THREADED STUD (2) Leave approximately 7/8” of the stud extending above 7/8"...

  • Page 8: How To Hang Your Ceiling Fan

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 8 4. How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 10). AT LEAST FLOOR Figure 10 WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs.
  • Page 9 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 9 4. How to Hang Your Ceiling Fan (continued) Screw the two 1-1/4” threaded studs (supplied) into the tapped holes in the hanger bracket (Figure 12). OUTLET BOX HANGER BRACKET 1-1/4" THREADED STUDS (2) Figure 12 NOTE: CEILING COVER, SUPPL Y Carefully lift the fan and seat the hanger ball/...

  • Page 10: How To Wire Your Ceiling Fan

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product for the ground wire. by Emerson Electric Co. could result in personal injury or property damage. WARNING Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for the ground wire.
  • Page 11 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 11 5. How to Wire Your Ceiling Fan (continued) Cut off the ends of the blue and yellow receiver wires and strip back insulation 1/2-inch from the ends of the Using wire connectors (supplied), make wiring wires.

  • Page 12: Warning

    To avoid possible fire or shock, make sure that the electrical wires are completely inside the outlet box and not pinched between the ceiling cover and the ceiling. Please call Emerson technical support 1-800-654-3545 if you have any questions about installation and operation of this ceiling fan.

  • Page 13: Light Kit Assembly

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 13 6. Light Kit Assembly Engage the white connector wire from the fan motor assembly to the light kit assembly white connector wire until you hear a snap (Figure 19). Engage the black connector wire from the fan motor assembly to the light kit assembly black connector wire until you hear a snap (Figure 19).

  • Page 14: Warning

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 14 6. Light Kit Assembly (continued) Screw the two 50-watt (maximum) halogen mini candelabra base bulbs in the light kit assembly sockets (Figure 21). NOTE: Do not touch halogen mini candelabra base bulb with bare hands. Fingerprints may result in shorter bulb life.

  • Page 15: No Light Cover Assembly

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 15 7. No Light Cover Assembly LIGHT KIT METAL BANDS (3) Removal of the glass from the glass assembly: Rotate the glass assembly counter-clockwise to dis- LIGHT KIT engage the screw heads from the assembly (Figure 23). PROTRUDING SCREW Remove the light kit assembly’s protruding screw heads...
  • Page 16 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 16 7. No Light Cover Assembly (continued) CLAMP SCREW Loosen the three glass assembly screws on the inside GLASS SHADE CLAMP of the glass assembly (Figure 25). RUBBER PAD Rotate the three glass shade clamps to free the glass GLASS SHADE shade.

  • Page 17: Wall Control Procedures

    Page 17 8. Wall Control Procedures Preset Memory Feature: Your Emerson receiver is Your Emerson Ceiling Fan/Light Control consists of wall equipped with a preset memory feature. If the AC mounted transmitter and a receiver which is mounted supply to the receiver is powered through a wall switch, under the fan ceiling cover.

  • Page 18: Turning

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 18 8. Wall Control Procedures (continued) SINGLE-POLE INSTALLATION WARNING CAUTION: To reduce the risk of electrical shock, Turning off wall switch is not sufficient. To avoid possible electrical shock, be sure electricity is turned disconnect the electrical supply circuit before off at the main fuse or circuit breaker box before installing the fan, light kit or receiver.

  • Page 19: Grounded As A Precaution Against Possible Electrical

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 19 8. Wall Control Procedures (continued) 3-WAY INSTALLATION (One fan controlled by two different wall controls) SW605 FAN/LIGHT (See Figures 30 and 31.) WALL CONTROL WARNING BLACK Turning off wall switch is not sufficient. To avoid LOAD TRAVELER possible electrical shock, be sure electricity is turned...
  • Page 20 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 20 8. Wall Control Procedures (continued) 3-WAY WIRING DIAGRAM: STANDARD WIRING FOR EXISTING NEW CONSTRUCTION 3-WAY CONTROLS NOTE: Retrofit 3-way installations are likely to EXISTING include two traveler wires between the two wall WALL CONTROL boxes.
  • Page 21 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 21 8. Wall Control Procedures (continued) IMPORTANT: Do not interrupt the conditioning until PROGRAMMING THE RECEIVER the fan comes to a complete stop in approximately OPERATING FREQUENCY & HIGH SPEED 5 minutes. All functions of the control will be CONDITIONING OF FAN CONTROL rejected during conditioning.
  • Page 22 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 22 8. Wall Control Procedures (continued) USING YOUR CEILING FAN WARNING POWER INDICATOR Fan installation must be completed, including the LIGHT installation of the fan blades, before testing the remote control. LIGHT AIRFLOW INTENSITY DIRECTION BUTTONS...

  • Page 23: Maintenance

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product The use of any other control not specifically approved by Emerson Electric Co. could result in personal injury for this fan could result in fire, shock and personal or property damage.

  • Page 24: Repair Parts

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 24 11. Repair Parts U.L. Model No.: CF4900...
  • Page 25 BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 25 11. Repair Parts Listing Model Numbers Description CF4900BS00 CF4900ORB00 CF4900VS00 Hanger Ball Assembly, Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod (4.5”) — — — Ceiling Cover (1)

  • Page 26: Trouble Shooting

    BP7485 Southtowne CF4900 12/4/13 10:15 AM Page 26 12. Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker blown. 1.

  • Page 27: Ceiling Fan Limited Warranty

    What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.

  • Page 28: Bp7485 Southtowne Cf4900 12/4/13 10:15 Am

    12/4/13 10:15 AM Page 28 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com...
