READ AND SAVE THESE INSTRUCTIONS
Fan Blades
Not Included
Ceiling Fan Owner's Manual
PREMIUM
SELECT
Model Numbers
CF4801AB00
CF4801AP00
CF4801BS00
CF4801CK00
CF4801GBZ00
CF4801GES00
CF4801ORB00
CF4801VNB00
CF4801WW00
Part No. F40BP74470000
23.8
Net Weight:
CROWN
SELECT
Model Numbers
CF4501AP00
CF4501GBZ00
CF4501GES00
CF4501VNB00
Lbs.
U.L. Model No.: CF4801 and CF4501
Form No. BP7447

Advertisement

Table of Contents
loading

Summary of Contents for Emerson PREMIUM SELECT CF4801AB00

  • Page 1 READ AND SAVE THESE INSTRUCTIONS Fan Blades Not Included Ceiling Fan Owner's Manual ™ ™ PREMIUM CROWN SELECT SELECT Model Numbers Model Numbers CF4801AB00 CF4501AP00 CF4801AP00 CF4501GBZ00 CF4801BS00 CF4501GES00 CF4801CK00 CF4501VNB00 CF4801GBZ00 CF4801GES00 CF4801ORB00 CF4801VNB00 CF4801WW00 23.8 Net Weight: Lbs. Part No.
  • Page 2 NOTE: All setscrews must be checked and re-tightened where necessary before installation. NOTE: This fan is suitable for use with solid-state speed controls. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan.
  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product 3. Remove the fan motor assembly from the by Emerson Electric Co. could result in personal protective plastic bag. Place all carton contents on injury or property damage.
  • Page 4: Electrical Requirements

    Electrical Requirements Your new ceiling fan will require a grounded electrical WARNING supply line of 120 volts AC, 60 Hz, 15 amp circuit. The outlet box must be securely anchored and Turning off wall switch is not sufficient. To avoid capable of withstanding a load of at least 50 pounds.
  • Page 5 How to Put Your Ceiling Fan Together (continued) 6. Install the setscrew (supplied in loose parts bag) in the motor coupling and tighten using the 5/32" setscrew wrench (supplied) (Figure 3). 7. Screw two 1” threaded studs (provided) into the DOWNROD motor (Figure 4).
  • Page 6 How to Put Your Ceiling Fan Together (continued) 11. Use four #10-24 x 12mm pan head screws and #10-24 x 12mm PAN HEAD flat washers (supplied) to secure flange to blade BLADE SCREW (4) (Figure 6). Repeat for the remaining four blades. FLAT WASHER (4) Illustration may not show the exact flange you are installing.
  • Page 7: How To Hang Your Ceiling Fan

    How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 9). WARNING AT LEAST The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 FLOOR kg.
  • Page 8: How To Wire Your Ceiling Fan

    Refer to the installation instructions and wiring diagrams supplied with the Emerson Fan Control Owner’s Manual. a. Connect the green grounding lead from the hanger ball and the green grounding lead from...
  • Page 9: Using Your Ceiling Fan

    REVERSE 1st Pull—HIGH SWITCH 2nd Pull—Medium 3rd Pull—Low 4th Pull—OFF 5. When operated by an Emerson Remote Control, check operation of fan and light in accordance with ACCENT LIGHT SPEED CONTROL PULL CHAIN the Remote Control Owner’s Manual. PULL CHAIN LARGE 6.
  • Page 10: Attaching Optional Light Kit

    Attaching Optional Light Kit To install an Emerson accessory light kit, remove the WARNING three screws securing the switch cup assembly to the fan, remove the switch cup assembly, and disconnect To avoid possible electrical shock, be sure electricity the connector. Remove the screw plug from the is turned off at the main service box before wiring.
  • Page 11: Troubleshooting

    Trouble Shooting WARNING: For your own safety, turn off power at fuse box or circuit breaker before trouble shooting your fan. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or 1.
  • Page 12: Repair Parts

    Repair Parts U.L. Model No.: CF4801 and CF4501...
  • Page 13: How To Order Repair Parts

    BP7447 BP7447 BP7447 BP7447 *Contact your nearest authorized Emerson fan dealer for optional blade accessories. Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: •...
  • Page 14 Uplight Lead Assembly 761790 761790 761790 761790 761790 Switch Uplight 761993-2 761993-2 761993-1 761993-1 761993-2 — Owner's Manual BP7447 BP7447 BP7447 BP7447 BP7447 *Contact your nearest authorized Emerson fan dealer for optional blade accessories. U.L. Model No.: CF4801 and CF4501...
  • Page 15 — — — Uplight Lead Assembly 761790 761790 761790 761790 Switch Uplight 761993-2 761993-2 761993-2 761993-1 — Owner's Manual BP7447 BP7447 BP7447 BP7447 *Contact your nearest authorized Emerson fan dealer for optional blade accessories. U.L. Model No.: CF4801 and CF4501...
  • Page 16: Limited Warranty

    If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson will refund the actual purchase price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product to Emerson Electric Co.
