1. INTRODUCTION

The K-array KTL22 is a unique product based on the simple idea of combining sound
and lighting into the same housing. It is ideally suited for architectural and display light
and sound installations and for background music, paging systems and program sound
applications. Deploying a KKS50 or other K-array bass speaker extends the frequency
response for full fidelity music reproduction.
The KTL22 has a solid aluminum chassis with an integral yoke bracket. Optionally, the
K-KTIP accessory allows the fixture to be hung as a pendant, putting sound and light in
the same location such as over tables in a bar or restaurant.
The speaker component is a single 30W 2" hi-efficiency neodymium element with a 32
Ohm impedance. Up to eight KTL22 can be parallel wired to a single channel of any of
the KA series amplifiers.
The lighting component consists of 2 Red, 2 Green, and 2 Blue 2.5W LEDs.
Colour mix and intensity is programmable via a 4-pin Phoenix connected to the
K-CTRL DMX controller.
The KTL22C is a version with integrated hardware for recessed ceiling mounting.
The elegant enclosure is small and light weight. With three mounting options it can be
installed almost anywhere. It comes finished in black or polished aluminum.

2. APPLICATIONS

• High-quality distributed systems for paging and music
• Exhibit audio for museum displays
• Architectural light and sound installations
• Space-sensitive fill for theatres
PRELIMINARY
KTL22
KTL22c
2" point source compact speaker
