KF12MT
1. INTRODUCTION
The KF12MT and the KF12P are K-array's newest multi-task additions to its portfolio of professional, high-quality loudspeakers in the
Redline Series. The KF12MT is a 12" coaxial full range multi-purpose powered speaker and is the successor to the long serving KF12
model.
Compared to its predecessor, this portable speaker features exciting updates. The KF12MT's integrated on-board touch screen with
matrix control provides intuitive managing and editing of powerful DSP controlling. Additional functionalities include: a delay up to
400ms, parametric filters for room eq, 2 analog + 2 digital inputs in AES/EBU, routing options, USB and Serial connections for remote
control and a full range powered output of 1000 W on 8 Ω. Having 2 analog or digital fully independent inputs on board can create real
stereo systems using one powered and one passive KF12P speaker. Thanks to its multi-purpose function, it can satisfy many different
venue requirements. It is ideally used as a stage monitor due to its wedge shape, as a stereo system with one active (KF12MT) and one
passive (KF12P), or as a main PA system for small and medium size events and more.
Designed and manufactured in Italy, the KF12MT and the KF12P give uncompromising sound quality in a small footprint and are
compatible with a variety of accessories. Housed in a black wood chassis and black steel grill, the KF12MT has a modern, sophisticated
look. Customized colors are available upon request.
2. APPLICATIONS
• Unique performance-to-size ratio
• Symmetrical horizontal and vertical coverage
• Angled cabinet for floor monitor use
• Integrated 35mm pole adapter for different uses
• Integrated DSP with multiple analog and digital inputs
• On-board touch screen with matrix control
• Configurable fullrange powered output
• RS485 and USB connectivity for remote control
7
3. KEY FEATURES
• Stage monitor on live stages
• Theatrical sound reinforcement
• Concert halls, clubs, houses of worship
• Portable and installed audio-visual systems
• Cinema and special effects
• Optimized for KF12P and KMT18P
REV. A
