Construction Features
Basic Geometric Design
Material
Finish
Hardware
Mount Points
Hang Points
Grill
Physical
Height
Width
Depth
Weight
EX12 ACCESSORIES
Heavy duty cover for EX12
COVER EX12
part name:
KVV 987 067
part number:
Heavy duty telescopic speaker
pole for ES/EX series
KV2-H
part name:
KVV 987 130
part number:
Top Hat Adapter for EX Brackets
Top Hat Adapter
part name:
KVV 987 090
part number:
-
including connection bolts
Joining Bracket for 2x EX12
EX12 Vetical Bracket Double
part name:
KVV 987 152
part number:
- including connection bolts and lifting eye
EX12 USER'S GUIDE
Asymmetrical Geometry
15mm Exterior Grade Baltic Birch
Ultra Wear Resistant Black Polymer Coating
One (1) Each Recessed Top Handle
One (1) Each Recessed Side Handle
One (1) Each "M10" Top Hang Point
Omnimount bracket points on Top and Side
Two (2) Each Integrated "M10" Side Hang Points
One (1) Each 1.375" (35mm) Pole Mount
Omnimount bracket points on Top
Two (2) Each Integrated "M10" Side
One (1) Each 1.375" (35mm) Pole Mount
Acoustically Designed Perforated Metal with Weather-Resistant Polymer
Coating
596mm (23.46")
368mm (14.48")
368mm (14.48")
27kg (60 lbs.)
Weather resistant cover for EX12
part name:
part number:
Heavy Duty Grill for EX12
part name:
part number:
Horizontal bracket for EX12
part name:
part number:
- including top hat cover adaptor
plate and two connection bolts
Vertical bracket for EX12
EX12
part name:
part number:
- including two connection bolts
EX12
APPENDIX A: EX12 SPECIFICATIONS
WEATHER RESISTANT
COVER EX12
KVV 987 190
HEAVY DUTY GRILL EX12
KVV 987 085
EX12 Horizontal Bracket
KVV 987 058
EX12 Vertical Bracket
KVV 987 057
P. 11
