ESD Series
User Guide
· ESD5 · ESD25 · ESD6 · ESD36 · ESD10 · ESD12 · ESD15
The Future of Sound.
Made Perfectly Clear.
At KV2 Audio our vision is to constantly develop technologies
that eliminate distortion and loss of information providing
a true dynamic representation of the source.
Our aim is to create audio products that absorb you,
place you within the performance and deliver a listening
experience beyond expectations.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KV2 Audio ESD Series
Summary of Contents for KV2 Audio ESD Series
-
Page 1: User Guide
· ESD5 · ESD25 · ESD6 · ESD36 · ESD10 · ESD12 · ESD15 The Future of Sound. Made Perfectly Clear. At KV2 Audio our vision is to constantly develop technologies that eliminate distortion and loss of information providing a true dynamic representation of the source. -
Page 2: Table Of Contents
ESD Series · Contents Contents ESD5 Overview Installation, Drawings Frequency characteristics Specifications ESD25 Overview Installation, Drawings Frequency characteristics Specifications ESD6 Overview Installation, Drawings Frequency characteristics Specifications ESD36 Overview Installation, Drawings Frequency characteristics Specifications ESD10 Overview Installation, Drawings Frequency characteristics Specifications... -
Page 3: Esd5
ESD5 · Overview ESD5 - part number KVV 987 340 The Ultimate Compact Passive System Application Specifically designed as a super- discreet passive loudspeaker for reproduction of recorded music and speech • Suitable in fixed installations as a full range speaker or as a system with accompanying subwoofers • Excellent peripheral reinforcement for main KV2 systems • Fill-in speaker... -
Page 4: Installation, Drawings
ESD5 · Installation · Drawings Installation The ESD5 is supplied with a single "ESD5 Wall Bracket", 2 locking screws with spacers and one 3 mm Allen key. Each ESD5 is quipped with two oval mounting apertures designed for easy vertical or horizontal attachment to the ESD5 Wall Bracket. -
Page 5: Frequency Characteristics
ESD5 · Frequency characteristics Frequency response Vertical Polarplots 125Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Horizontal Polarplots 125Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz... -
Page 6: Specifications
ESD5 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 112dB Max SPL Peak 115dB -3dB Response 130Hz to 22kHz -10dB Response 74Hz to 28kHz Recommended Power 100W Sensitivity 89dB Impedance 16Ω Crossover Point 3.0kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 90°... -
Page 7: Esd25
ESD25 · Overview ESD25 - part number KVV 987 368 2-Way Full-Range Compact Low Profile Passive Loudspeaker Application Specifically designed as a super- discreet passive loudspeaker for reproduction of recorded speech and music • Suitable in fixed installations as a full range speaker or as a system with accompanying subwoofers • Excellent peripheral reinforcement for main KV2 systems • Fill-in speaker... -
Page 8: Installation, Drawings
ESD25 · Installation · Drawings Installation The ESD25 is supplied with a single "ESD25 Wall Bracket", 2 locking screws with spacers and one 3 mm Allen key. Each ESD25 is equipped with two oval mounting apertures designed for easy vertical or horizontal attachment to the ESD25 Wall Bracket. -
Page 9: Frequency Characteristics
ESD25 · Frequency characteristics Frequency response Vertical Polarplots 125Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 125Hz 500Hz 4kHz 250Hz 1kHz 8kHz 2kHz 16kHz Horizontal Polarplots 125Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 125Hz 500Hz 4kHz 250Hz 1kHz 8kHz 2kHz... -
Page 10: Specifications
ESD25 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 118dB Max SPL Peak 121dB -3dB Response 120Hz to 22kHz -10dB Response 72Hz to 28kHz Recommended Power 200W Sensitivity 92dB Impedance 8Ω Crossover Point 3.0kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 90°... -
Page 11: Esd6
ESD6 · Overview ESD6 - part number KVV 987 206 The Ultimate Compact Passive System Application Specifically designed as a passive loudspeaker for reproduction of recorded music in small areas • Suitable in Fixed installations as full range stand-alone or with subwoofers • Excellent peripheral reinforcement for main KV2 systems • Portable PA for Multi-Media applications... -
Page 12: Installation, Drawings
ESD6 · Installation · Drawings Installation Installations should be carried out using KV2 Audio’s horizontal or vertical U brackets. They are mounted vertically using M10 points located on the side of the cabinet or in the top handle and bottom M10 plate (supplied with horizontal bracket) for horizontal fixing and to a mounting post with a diameter of 35 mm using a support flange. -
Page 13: Frequency Characteristics
ESD6 · Frequency characteristics Frequency response Horizontal Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Vertical Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz... -
Page 14: Specifications
ESD6 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 117dB Max SPL Peak 120dB -3dB Response 68Hz to 20kHz -10dB Response 51Hz to 28kHz Recommended Power 175W Sensitivity 92dB Impedance 16Ω Crossover Point 2.0kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 100°... -
Page 15: Esd36
• Domestic and Professional studio monitoring Introduction One of the more unique loudspeakers offered by KV2 Audio the ESD36 is a passive, full-range 3-way speaker system for speech and music reproduction. The ESD36 features a 6" driver dedicated to high quality mid-range reproduction and a further two low frequency 6"... -
Page 16: Installation, Drawings
ESD36 · Installation · Drawings Installation Installations should be carried out using KV2 Audio's horizontal or vertical U brackets. They are mounted vertically using M10 points located on the side of the cabinet or in the top handle and bottom M10 plate (supplied with horizontal bracket) for horizontal fixing and to a mounting post with a diameter of 35 mm using a support flange. -
Page 17: Frequency Characteristics
ESD36 · Frequency characteristics Frequency response Horizontal Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Vertical Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz... -
Page 18: Specifications
ESD36 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 122dB Max SPL Peak 125dB -3dB Response 65Hz to 25kHz -10dB Response 57Hz to 30kHz Recommended Power 350W Sensitivity 94dB Impedance 8Ω Crossover Point 600Hz, 2.5kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 100°... -
Page 19: Esd10
• Large conference and small to medium performance venues • Multi-purpose fixed installations • Personal monitoring • In-fill for larger main KV2 Audio systems or third party systems Introduction The ESD10 is a compact passive 2-way, high output, full-range loudspeaker incorporating a 10" trans-coil woofer and a wide dispersion rotatable horn. -
Page 20: Installation, Drawings
ESD10 · Installation · Drawings Installation Installations should be carried out using KV2 Audio's horizontal or vertical U brackets. They are mounted vertically using M10 points located on the side of the cabinet or in the top handle and bottom M10 plate (supplied with horizontal bracket) for horizontal fixing and to a mounting post with a diameter of 35 mm using a support flange. -
Page 21: Frequency Characteristics
ESD10 · Frequency characteristics Frequency response Horizontal Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Vertical Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz... -
Page 22: Specifications
ESD10 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 125dB Max SPL Peak 128dB -3dB Response 65Hz to 20kHz -10dB Response 56Hz to 30kHz Recommended Power 500W Sensitivity 96dB Impedance 4Ω Crossover Point 1.8kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 100°... -
Page 23: Esd12
ESD12 · Overview ESD12 - part number KVV 987 199 The Ultimate Passive System Application Designed as a passive loudspeaker for the highest quality vocal and full range live performance in medium areas • Suitable for medium to large conference, Theatre and small to medium scale concerts • Scalable from stand alone to full range large systems by adding subwoofers... -
Page 24: Installation, Drawings
ESD12 · Installation · Drawings Installation Installations should be carried out using KV2 Audio's horizontal or vertical U brackets. They are mounted vertically using M10 points located on the side of the cabinet or in the top handle and bottom M10 plate (supplied with horizontal bracket) for horizontal fixing and to a mounting post with a diameter of 35 mm using a support flange. -
Page 25: Frequency Characteristics
ESD12 · Frequency characteristics Frequency response Horizontal Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Vertical Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz... -
Page 26: Specifications
ESD12 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 127dB Max SPL Peak 130dB -3dB Response 55Hz to 22kHz -10dB Response 50Hz to 30kHz Recommended Power 500W Sensitivity 98dB Impedance 4Ω Crossover Point 1.2kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 80°... -
Page 27: Esd15
ESD15 · Overview ESD15 - part number KVV 987 313 The Full Range Passive System Application Specifically designed as a true full-range, passive loudspeaker for high quality, high output portable music playback and live performance in small areas • High quality fixed installations without subwoofer • Small live performances • Church installations • Conferences... -
Page 28: Installation, Drawings
ESD15 · Installation · Drawings Installation Installations should be carried out using KV2 Audio's horizontal or vertical U brackets. They are mounted vertically using M10 points located on the side of the cabinet or in the top handle and bottom M10 plate (supplied with horizontal bracket) for horizontal fixing and to a mounting post with a diameter of 35 mm using a support flange. -
Page 29: Frequency Characteristics
ESD15 · Frequency characteristics Frequency response Horizontal Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz 250Hz 2kHz 16kHz Vertical Polarplots 73Hz - 250Hz 500Hz - 2kHz 4kHz - 16kHz 73Hz 500Hz 4kHz 125Hz 1kHz 8kHz... -
Page 30: Specifications
ESD15 · Specifications Specifications System Acoustic Perfomance Max SPL Long-term 126dB Max SPL Peak 129dB -3dB Response 48Hz to 18kHz -10dB Response 45Hz to 28kHz Recommended Power 500W Sensitivity 97dB Impedance 4Ω Crossover Point 500Hz, 2.5kHz High Frequency Section Acoustic Design Horn Loaded High Horn Coverage Horizontal / Vertical 80°... -
Page 31: Accessories
ESD Series · Accessories PADDED HEAVY DUTY COVERS Cover for ESD6 Cover for ESD36 part name: part name: Cover ESD6 Cover ESD36 part number: part number: KVV 987 210 KVV 987 260 description: description: - heavy duty - heavy duty... - Page 32 ESD Series · Accessories Horizontal Bracket for ESD10 Vertical Bracket for ESD10 part name: part name: EX10 Horizontal Bracket EX10 Vertical Bracket part number: part number: KVV 987 036 KVV 987 033 description: description: - for EX10, ESD10 - for EX10, ESD10...
-
Page 33: Speaker Cables
ESD Series · Accessories Speaker cables part name: part name: 1m - round flexible speaker cable, 1m - round flexible speaker cable, cross section 2 x 1.5mm cross section 4 x 2.5mm part number: part number: WX 002 WX 003... -
Page 34: Warranty · Service
If the unit needs to be shipped back to the factory, it must be sent in its original carton. If improperly packed, the unit may be damaged. To obtain service, contact your nearest KV2 Audio Service Centre, Distributor or Dealer. -
Page 35: Notes
ESD Series · Notes... - Page 36 ESD Series · Notes...
- Page 37 ESD Series · Notes...
- Page 38 The Future of Sound. Made Perfectly Clear. KV2 Audio International Nádražní 936, 399 01 Milevsko Czech Republic Tel.: +420 383 809 320 Email: info@kv2audio.com www.kv2audio.com KVV120050-00-16-0...
