Preface
This manual covers the basic configuration and installation of the TrangoLINK‐45 Wireless Point to Point Broadband
System, and applies to the following radio part numbers:
P5055M‐19‐xx
P5055M‐23‐xx
P5055M‐EXT‐xx
Where "xx" denotes the regulatory configuration of the unit as follows:
US: For use in the USA
IC: For use in Canada
EU: For use in the following EU member and non‐member countries:
Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland (Non
Members), Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Norway (Non Members), Poland, Portugal, Slovak Republic,
Slovenia, Spain, Sweden, Netherlands, United Kingdom, Switzerland (Non Members),Bulgaria, Romania
OE: OEM model for individual certification in other countries
Each radio unit is supplied with the proper mounting hardware, a power adapter, and POE box with LED indicators. Cables
must be supplied by the installer.
Two radio units are required to make a TrangoLINK‐45 link. The P5055M‐EXT‐xx must be used in conjunction with an approved
external antenna (sold separately). Instead of an internal antenna, the P5055M‐EXT‐xx has two reverse polarity SMA RF
Connectors for the attachment of external antenna cables.
FCC Information
FCC ID: NCYP5055M
The TrangoLINK‐45 System is used for point‐to‐point operation only.
NOTE: The P5055M‐EXT‐xx requires professional installation due to FCC limits on output power settings when operating in
the UNII band.
This device complies with Part 15 of the FCC Rules and Regulations. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio‐frequency energy and, if not installed and used in accordance with these
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in any particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
correct the interference by one of more of the following measures:
1) Reorient the antenna.
2) Increase the separation between the affected equipment and the unit.
3) Connect the affected equipment to a power outlet on a different circuit from that which the receiver is connected to.
4) Consult the dealer and/or experienced radio/TV technician for help.
LT‐9037A
Radio unit with internal 19 dBi patch antenna array
Radio unit with internal 23 dBi patch antenna array
Radio unit with external RP‐SMA antenna connectors
August 15, 2011
TL45 User Manual Rev 2.0r3
Page 4
