Preface

Preface
This manual covers the basic configuration and installation of the ATLAS4900 Wireless Point to Point Broadband
System, and applies to the following radio part numbers:
P4900M-INT-18
P4900M-INT-22
P4900M-EXT
The ATLAS4900-INT-18 and –INT-22 products consist of two radios which have either internal 18 or 22 dBi antennas
with electronically selectable polarization. The –EXT radios are designed for use with external dish antennas. All three
products contain universal power adapters and mounting hardware for a pole. This device requires professional
installation and a license.

FCC Information

This device complies with Part 90 of the FCC Rules and Regulations.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in
accordance with these instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in any particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
correct the interference by one of more of the following measures:
1) Reorient the antenna.
2) Increase the separation between the affected equipment and the unit.
3) Connect the affected equipment to a power outlet on a different circuit from that which the receiver is connected to.
4) Consult the dealer and/or experienced radio/TV technician for help.
FCC ID: NCYP4900M
IMPORTANT NOTE:
Intentional or unintentional changes or modifications must not be made unless under the express consent of the party
responsible for compliance. Any such modifications could void the user's authority to operate the equipment and will
void the manufacturer's warranty. To comply with FCC RF exposure requirements, the following antenna installation and
device operating configurations must be satisfied. The antenna for this unit must be fixed and mounted on outdoor
permanent structures with a separation distance of at least two meters from all persons. Furthermore, it must not be co-
located or operating in conjunction with any other antenna or transmitter.

Warranty Information

Radios from Trango Broadband Wireless are warranted for one year from date of purchase. Please see
www.trangobroadband.com
Trango Broadband Wireless — Atlas4900 User Manual Rev. 1.3
Atlas4900-INT18 point-to-point radio with integrated 18 dBi panel antenna
Atlas4900-INT22 point-to-point radio with integrated 22 dBi panel antenna
Atlas4900-EXT point-to-point radio with external h/v polarization antenna connectors
for a complete description of warranty coverage and limitations.
page iii
