Step 2: Set Switches on the Scan Assembly Circuit Board

About the SW5 and SW6 DIP Switch Settings

Setting DIP Switches SW5 and SW6

Document 800-02460 Rev A
08/08
The scan assembly printed circuit board (PCB) has DIP switches SW5 and SW6 that
require setting as detailed in
SW5 sets the protocol to IntelliBus and switch SW6 sets the baud rate to 38400 (positions
1 to 4) and No Parity (positions 5 and 6).
Leave SW5-8 ON. Setting the DIP switch SW5-8 to OFF enables a user to change the
address, protocol, baud rate and parity from the OSD menu (which is not recommended
with most installations).
Set the DIP switches on the scan assembly printed circuit board as required for your
system configuration. Use
.
Table 1-6
ACUIX IP DIP Switch Settings (SW5 and SW6)
1
2
3
SW5 - Set for IntelliBus Protocol
OFF
OFF
OFF
SW6 - Set Baud Rate to 38400 and No Parity
OFF
ON
ON
ACUIX IP Rugged Housing and Dome Installation Guide
Table 1-6
so that the ACUIX IP dome works correctly. Switch
Figure 1-5
and
Table 1-6
Switch Position
4
5
OFF
OFF
OFF
OFF
to help set it correctly.
6
7
8
OFF
OFF
ON
OFF
OFF
OFF
17
