Related Documents

Document title or link
ACUIX IP High Speed Digital Dome User Guide
ACUIX IP Quick Installation Guide
Honeywell Video online literature
http://www.honeywellvideo.com/support/literature/index.html
Access PDF versions of data sheets, quick references, installation and user guides,
specifications, product notices and other useful material

Wiring and Power Cautions and Requirements

Wiring and Power Cautions

Document 800-02460 Rev A
08/08
Table 1-1
Related Documents and External Links
To make good wire contact and ensure the wire does not short to adjacent
wires, fully insert the wire in the hole on the terminal strip.
A good earth ground must be connected at J1, pin 2. Surge suppression is not
provided if the unit is not connected to a good earth ground.
Ensure there are no bare wires touching or faulty operation may occur.
Ensure the cabling does not interfere with the rotation of the pan and tilt
assembly.
To maintain 24 VAC ± 10% at each dome, the proper wire size for the distance
and the number of domes must be determined.
For CE compliance, the power supply must be connected to a CE approved
240V UPS (uninterruptible power supply). See
supplies which must be used to meet FCC and UL requirements.
ACUIX IP Rugged Housing and Dome Installation Guide
Table 1-4
Part number
800-00336
800-00020
for a list of the power
