ACUIX IP Rugged Housing and Dome
16
Figure 1-2
J6 Terminal Block Alarm Connection
Alarm 2
Alarm 3
Alarm 1
Figure 1-3
Ferrite Bead Installation Location
Figure 1-4
Rugged Housing Cable Access Hole
Alarm 4
Mounting bracket
Pull wiring through
access hole and
attach the ferrite
bead clamp
Ferrite bead clamp
installed on the cable
extending from the
housing
