Communications Overview
The reader's default communications mode is RF (Bluetooth).
RF (Bluetooth)
RF (Bluetooth) enables wireless two-way communication between the reader and the
Charging Station with Embedded Modem and allows you to decode symbols. The reader
must be in this mode to communicate with ESP.
USB Native (HID)
USB Native (HID) allows the reader to communicate with the PC via a wired connection. You
must move the switch on the Charging Station with Embedded Modem to the OFF position (to
the left, opposite the direction of the arrow on the switch). This mode of communication is
useful when the reader is storing decoded symbol data and will send the data to the PC when
placed in the Charging Station with Embedded Modem. It is not possible to connect to ESP in
this mode.
USB Keyboard
USB Keyboard causes the reader to appear to the PC as a keyboard. You must move
the switch on the Charging Station with Embedded Modem to the OFF position (to the left,
opposite the direction of the arrow on the switch). This mode allows ASCII characters to
be transmitted as keyboard sequences. It is not possible to connect to ESP in this mode.
HS-51/HS-51X Wireless Handheld Reader User Manual
Communications
4-3
