Install the Battery
Battery Installation
Install the battery in the reader as shown below. The latch will snap and the battery will
lock into place.
To remove the battery, slide the latch to the right and then pull gently on the cartridge.
Push the
battery
into place.
Battery Life LEDs
Press the battery life button to the left of the LEDs to check the amount of battery life
remaining. If the battery has less than 10% capacity, the first LED will flash quickly. If the
battery has greater than 25% capacity, the LEDs will illuminate and remain illuminated for
four seconds.
Battery life button
This table shows battery life LED behavior for different levels of battery life.
Battery Life
<10%
Rapid flashing
<25%
25-50%
50-75%
>75%
HS-51/HS-51X Wireless Handheld Reader User Manual
The latch will snap when the battery is fully
in place. Slide the latch to the right and pull
gently to release the battery.
ON
ON
ON
ON
ON
ON
ON
Battery life LEDs
ON
ON
Quick Start
ON
1-3
