- Page 1 13.3” LOW VOLTAGE BedMate II DTV Operations Manual MODEL# BM13II REVISION 2.0...
-
Page 3: Table Of Contents
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL TABLE OF CONTENTS Channel Roll Power Roll SAFETY INSTRUCTIONS Parental Control 20, 21 Password PACKAGE CONTENTS VCHIP US V-VHIP PRODUCT INTRODUCTION Movie Rating TV Rating IR Remote Control Canada V-CHIP I/O Panels English Keypad French INSTALLATION... -
Page 4: Regulatory Information
1. Increase the separation between the equipment and receiver. 2. Consult the dealer or an experienced radio/TV technician for help. CAUTION Do not attempt to modify this product in any way without written authorization from HealthCare Information, LLC. Unauthorized modification will void the warranty of the product. CAUTION Danger of explosion if battery is incorrectly replaced. - Page 5 Use only the following UL Listed arms with the BedMate II Model numbers BM13II. Model Arm X CAUTION Use only the following UL Listed power supplies with the BedMate II Model number BM13II. PS10, PSI, WM-PSI-LB-ER, WM-PSI-LB, WM-PSI-SB, PSI 120/24, WM-PS-LB120/24E, WM-PS-LB120/24E, WM-PS-SB120/24E, WM-PS-SB120/24I COMPLIANCE The party responsible for this product’s compliance is:...
-
Page 6: Safety Instructions
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 7: Package Contents
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PACKAGE CONTENTS After opening, carefully check the package contents: 13.3” BedMate II Low Voltage LCD-TV IR Remotes are shipped per order. Manuals are shipped per order* *The latest version of this manual can be downloaded from www.hci-tv.com... -
Page 8: Product Introduction
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PRODUCT INTRODUCTION IR Remote Control POWER TURNS SET ON AND OFF MUTE TURNS SOUND ON AND OFF VOLUME UP INCREASES SOUND LEVEL SOURCE SELECTS INPUT SOURCE TURNS CLOSED CAPTIONS ON AND OFF VOLUME DOWN DECREASES SOUND LEVEL... - Page 9 ----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PRODUCT INTRODUCTION REAR I/O PANEL FRONT PANEL RIGHT SIDE PANEL NOTE: The CC button may also be used to control the Mute function. See page HealthCare Information, LLC...
-
Page 10: I/O Panels
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL HealthCare Information, LLC... -
Page 11: Installation
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL INSTALLATION Before installing, carefully read the “Important Safeguards” section on pages 4 and 5. These mounting instructions cover all HCI BedMate TVs. The number of cables may vary between models. RM13II sets will typically have only a coax cable and optional RG-6 cable. - Page 12 DO NOT OVER TIGHTEN. 1/16 TO 1/8 TURN PAST FINGER TIGHT IS ENOUGH. The power cable and Cat5e cables are not used with the BedMate II and do not need to be connected. HealthCare Information, LLC...
- Page 13 ----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL If present connect the CAT5 and power cables. (BedMate III only) Arrange the cable(s) into the nose. Reinstall the Nose covers. Plug in the power supply and proceed to setup. HealthCare Information, LLC...
-
Page 14: Basic Connections
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL BASIC CONNECTIONS PC (to use TV as a monitor) Use a male to male VGA cable to connect a computer VGA output to the PC VGA input on the back of the set. Make sure the computer resolution is set equal to or lower than 1280 x 800. -
Page 15: Setup And Operation
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL SETUP AND OPERATION Installing the IR Remote Control Batteries Turn the IR Remote over. Press down on the arrow and slide the battery cover off the bottom. Install the two included AAA batteries. The polarity is indicated on the bottom of the battery compartment. -
Page 16: Advanced Setup
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL ADVANCED SETUP Enter function code “9999” and press the “SETUP” button on the IR remote to enter the main setup menu. See pages 29 and 30 for a full menu tree. Use the navigation buttons to select and change menu items. Press the "BACK" button to go back one menu level, press "ENTER"... -
Page 17: Pc Settings
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Adjusts screen settings for using set as a computer monitor. Input must be set to VGA to adjust these Settings settings. Auto Adjust Automatically adjust screen size to match VGA input. Horizontal Adjusts the horizontal position of the picture. -
Page 18: Base
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Bass Set bass level when Sound Mode is set to User. Treble Sets treble level when Sound Mode is set to User. Balance Sets left/right balance. Only effects head phones. Note: Bass, Treble and Balance can only be adjusted if Sound Mode is set to User. -
Page 19: Channel
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL CHANNEL Channel Add channel labels and Bank (tier) setup. Setting Channel Current channel being edited. Channel is displayed behind menu. Use left/right arrow keys Number to change. Channel Sets channel label. Use left/right arrow buttons to select character to edit. Green underscore Label indicated character being edited. -
Page 20: Advanced Setting
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Press the “ENTER” button. Enter the Virtual Channel number using the keypad then press enter. To clear a Virtual Channel number select the Virtual Channel in the NUM column and press the ENTER button twice. NOTE: Each time you enter a Virtual Channel number the TV does a check to make sure the Virtual Channel number has not already been used. -
Page 21: Parental Control
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PARENTAL Sets parental control parameters to restrict viewing. The first time you enter the parental control you will CONTROL have to enter a password to continue. To enter a password: Select Change Password Select New PIN Enter New PIN Selection will automatically switch to Confirm. -
Page 22: Block Unrated Shows
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL When selected blocks unrated TV shows and TV movies. Press the “ENTER” Block Unrated button to turn on/off. Shows Down Feature not available in USA at this time. Loadable Rating Clear Feature not available in USA at this time. -
Page 23: Closed Caption
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Analog Sets which Closed Caption or text message will be displayed for analog channels. Selections Caption are: Type CC1- CC2 – CC3 – CC4 – TEXT1 – TEXT2 – TEXT3 – TEXT 4 NOTE: Not all stations and programs will contain Closed Captions or Text. Most channels and shows that have closed captions will only have CC1 and maybe CC2. -
Page 24: Power On Setting
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Osd Time Set how long the OSD menu is displayed in seconds. Selections are: 10 s – 20 s – 30 s – 40 s – 50 s – 60 s – Always NOTE: When Always is selected OSD will not time out. The Always settings will remain in effect until changed or the set is turn off. -
Page 25: Ch No On
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Ch No Turn On channel. Set will turn on to this channel. Set to 0 to turn on to channel TV was on when turned off. Input Source should be set to TV. Volume Turn on volume setting. Set to zero to turn on to same volume level when set was turned off. -
Page 26: Tv Max Volume
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL TV Max Vol Sets maximum sound level TV can be set to when Spk Mode is set to TV only. PS Max Vol Sets maximum sound level TV can be set to when Spk Mode is set to Pillowspeaker. -
Page 27: Music Play Repeat
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Information Off – 10sec – All time Music Auto When on automatically plays music files when detected. Play Information Software Version Information. Software version can also be viewed by pressing the VOL- and CH- buttons of the front panel at the same time or entering function code “9999”. -
Page 28: Pillow Speaker Operation
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PILLOW SPEAKER OPERATION See page 24 for information on pillow speaker type selection. See pages 17 and 25 to disable the TV’s internal speakers or turn on pillow speaker sound. The BM13II has a ¼” jack for pillow speaker connection. A one button analog pillow speaker, digital pillow speaker set for Zenith or Philips code, HCI Visitor station or a Sip and Puff device can be used. -
Page 29: Functions
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL FUNCTIONS Functions are accessed by pressing the “FUNCTION” button on an IR remote. Each time the “FUNCTION” button is pressed the next function will be displayed. After about 10 seconds of no activity the function screen will turn off. The functions are:... -
Page 30: Menu Tree
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL MENU TREE HealthCare Information, LLC... - Page 31 ----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL HealthCare Information, LLC...
-
Page 32: Parental Control
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL PARENTAL CONTROL TV RATINGS United States TV-Y Content appropriate for all ages. TV-Y7 Content may not be suitable for children under 7 years of age. TV-Y7-FV Content may not be suitable for children under 7 years of age. Contains fantasy violence. - Page 33 ----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Canadian Ratings Content suitable for children under 8 years of age. No profanity or sexual content. Minimal comedic violence. Content suitable for children over 8 years of age. No profanity. Occasional “socially offensive and discriminatory” language allowed if in the content of the story.
-
Page 34: Key Define
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL KEY DEFINE The functions of some front panel buttons can be redefined. To change the functions: Enter the setup menu. See page 14. Select “Keypad definition” in the “Others” menu and press the right arrow button. -
Page 35: Virtual Channels
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL VIRTUAL CHANNELS Using the virtual channel mapping feature of your HCI television, will allow you to make a custom channel lineup. You can assign both analog and digital channels a virtual channel number, different from the one given from your cable company. -
Page 36: Banks
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL BANKS Banks, also known as tiers, allows the set to have up to 4 different channel lineups that can be easily switched to without reprogramming the set. The banks are useful in rental applications where one bank can be only free channels and the three remaining banks can include various premium channels. -
Page 37: Specifications
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL SPECIFICATIONS DIMENSIONS HealthCare Information, LLC... -
Page 38: Specifications
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL GENERAL SPECIFICATIONS Cabinet Color Standard color USA– Cool Grey, Custom colors available Standard color Canada – Tan with maple leaf symbol. Dimensions L15.35 x W2.58 x H10.04 Inches Weight (Lbs) 8.5 Lbs Shipping Weight (Lbs) 12.8 Lbs Shipping Dimensions (mm) (L) 23.78 x (W) 10.04 x (H) 20.35 Inches... - Page 39 ----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL Digital Media Video Formats Supported MPEG - 1, MPEG - 2, MPEG - 4, WMV, WMV - HD, AVI Photo Formats Supported JPEG, BMP, GIF, PNG Music Formats Supported MP2, MP3, WMA, WMA - Pro Special Features...
-
Page 40: Warranty
----------------------------------------------------------------------------------BedMate II OPERATIONS MANUAL WARRANTY HCI Television product Limited Warranty HCI warrants, to the original purchaser only that all new HCI televisions (excluding any equipment manufactured by others and included in HCI shipment) are free from defects in material for a period of two years from the date of shipment. - Page 41 HCI ALSO OFFERS 22”, 26”, 32, & 42” SIZES ©Copyright 2011, HealthCare Information, LLC...
