REPAIR PARTS
SNOW THROWER - MODEL NO. 1130SB-LSB
2
2
KEY PART
NO. NO.
1 532 42 11-60
2 817 50 10-10
*3 532 42 06-78
*4 532 42 11-61
*5 532 42 06-75
*6 532 42 11-62
NOTES:
1. ITEMS INDICATED WITH AN * ARE LISTED AS REFERENCE FOR SERVICE PARTS ONLY.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1130SB-LSB (96193003800), PRODUCT NO. 961 93 00-38
*3
*6
DESCRIPTION
LEVER/CABLE ROTATOR ASSEMBLY GRAY
SCREW 10−24 X .625
ROTATOR HEAD
ROTATOR PIVOT BRACKET
PULLEY PIVOT
CABLE ASSEMBLY GRAY
NOTE: All component dimensions given in U.S. inches.
CONTROL PANEL / DISCHARGE CHUTE
1 inch = 25.4 mm
