Husqvarna 1130SB-LSB Owner's Manual page 22

REPAIR PARTS
SNOW THROWER - MODEL NO. 1130SB-LSB
2
3
NOTE: All component dimensions given in U.S. inches.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1130SB-LSB (96193003800), PRODUCT NO. 961 93 00-38
1
4 (5x)
2
01.07.023-B
1
01.07.007-A
AUGER HOUSING / IMPELLER ASSEMBLY
3 (5x)
KEY PART
NO. NO.
1 532 42 17-13
2 532 40 76-45
3 872 27 05-05
4 532 15 53-77
2
1
KEY PART
NO. NO.
1 532 18 81-70
2 532 41 18-33
3 532 17 95-82
22
DESCRIPTION
AUGER HOUSING
SCRAPPER BAR
CARRIAGE BOLT 5/16−18 X .625
NUT 5/16−18
3
DESCRIPTION
PLASTIC RETAINER
AUGER BALL BEARING
SCREW 5/16−18 X 1.00
1 inch = 25.4 mm
