features menu

The factory default settings are indicated in bold text in the table below.
FEATURE LED ON SETTING
NUMBER
1 Engine checking on
2 Tachometer checking type
3 12 minutes run time (1)*
4 Flashing parking light output
5 Cranking time 0.6 sec. (1)
6 Voltage check high level
7 No function
8 Activation pulse: 1 (1)
9 Ignition/accessory output: Ignition
10 Accessory state during wait to start: OFF
2 nd status output: Normal (1)
11
12 Diesel timer Wait-to-Start input (1)
13 No function
14 Door Lock pulse duration 0.8 seconds (1)
15 Unlock output 1 pulse
16 Lock output 1 pulse
17 Ignition unlock ON
18 Ignition lock ON
19 Factory Alarm Disarm function with unlock
20 Factory Alarm Disarm 1 pulse
21 No Function
*NOTE: The number in parentheses indicate the number of times the LED will flash
30
LED OFF SETTING
Engine checking off
Voltage checking type
24 minutes (2)*, 60 minutes (3) run time
Constant parking light output
Cranking time 0.8 (2), 1.0 (3), 1.2 (4), 1.4 (5),
1.6 (6), 1.8 (7), 2.0 (8), 4.0 (9) sec.
Voltage check low level
Activation pulses: 2 (2), 3 (3)
Ignition/accessory output: Accessory
Accessory state during wait to start: ON
Rear defogger latched (2)/pulsed (3)
Timed 15 (2), 30 (3), 45 (4) seconds
3.5 (2), 0.4 (3) seconds
Unlock output 2 pulses
Lock output 2 pulses
Ignition unlock OFF
Ignition lock OFF
Before Unlock (2)/Remote Start only (3)
2 pulses
