tach learning

to learn the tach signal

1.
DRW-96
2.
3.
4.

operating settings learn routine

The System Features Learn Routine dictates how the unit operates. The programmable operating settings of this
unit can be changed whenever necessary through the computer-based Learn Routine. The Program push-button
switch, plugged into the blue port, is used together with a programmed transmitter to change the settings. It is
possible to access and change any of the feature settings using the Program switch. To program settings, remem-
ber: Key, Choose, Transmit and Release.
To program the learn routine:
1.
2.
Once the Program switch has been pressed and released the desired number of times, press it once more and
HOLD it. After a second, the LED will flash to indicate which feature you have accessed. For example, groups of
eight flashes would indicate access to the activation pulse feature (Feature 8).
28
Start the vehicle with the key.
Within 5 seconds, press and HOLD the Program switch.
The LED will light constant when the tach signal is learned.
Release the Program switch.
Key. Turn the ignition on and then back off.
Choose. Within 10 seconds, press and release the Program switch the number of times cor-
responding to the feature number you want to program. (See Features Menu section.)
