Auto Mate 3303A Owner's Manual

Hide thumbs Also See for 3303A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Since its inception, Directed has had one
purpose, to provide consumers with the fin-
est vehicle security and car stereo prod-
ucts and accessories available. The recipient
of nearly 100 patents and Innovations Awards
in the field of advanced electronic technology.
Quality Directed products are sold and ser-
viced throughout North America and around
the world.
Call (800) 274-0200 for more information
about our products and ser vic es.
© 2012 Directed. All rights reserved.
www.automatecarsecurity.com
Vista, CA 92081
Directed is committed to delivering world-
class quality products and services that excite
and delight our customers.
QRG3303A 2012-06
O W N E R' S
Vehicle Security System
G U I D E
MOD EL
3303A

Advertisement

Table of Contents
loading

Related Manuals for Auto Mate 3303A

Summary of Contents for Auto Mate 3303A

  • Page 1 © 2012 Directed. All rights reserved. QRG3303A 2012-06 www.automatecarsecurity.com MOD EL Vista, CA 92081 Directed is committed to delivering world- O W N E R’ S G U I D E 3303A class quality products and services that excite and delight our customers.

  • Page 2: What You Get

    Congratulations Congratulations on the purchase of your state-of-the-art security and remote start system. Reading this Owner’s Guide prior to using your system will help maximize the use of your system and its many fea- tures. Please visit: www.automatecarsecurity.com – For general and additional guide information.

  • Page 3: Government Regulations And Safety Information

    Government Regulations and Safety information Read the Government Regulations and Warning! Safety First sections of this manual prior to operating this system. Warning! Failure to heed this information can result in death, personal injury or property damage and may also result in the illegal use of the system beyond its intended purpose.

  • Page 4: Table Of Contents

    Contents Government Regulations and Safety information ........... 2 Responder LC 2-Way................... 2 Status Screen Icons ....................4 Using your System ....................7 Commands and Confirmations .............. 7 Performing Commands ................. 7 Responder LC Command table .............. 8 Basic Commands (Direct Access) ................9 Arm ....................

  • Page 5: Responder Lc 2-Way

    Responder LC 2-Way Internal Antenna Display Function Button Command Mini-USB Port Buttons Feature Description Internal Antenna Used for transmitting and receiving information Display Status screen - the upper portion of the display contains status icons for the system, siren, alarm zones, and remote control Text field - the lower portion of display shows the clock, command confirmations, page messages and programming menus...
  • Page 6 Control Center Control button Status LED The control center, typically located on the upper part of the front windshield sends and receives commands or messages to and from your system. It consists of: The In-vehicle system antenna, for 2 way communication. The Status LED, as a visual indicator of the system’s status.

  • Page 7: Status Screen Icons

    Status Screen Icons Status Screen Icons Text Field The table below describes all the status screen icons. Icon Description Armed: The system is armed, the alarm is enabled Locked: The system is locked in valet, the alarm is disabled Disarmed: The system is disarmed, the alarm is disabled Unlocked: The system is unlocked in valet, the alarm is disabled Siren is disabled for sensor triggers;...
  • Page 8 Icon Description On during a sensor zone full trigger output On during fault report to indicate a sensor is active and bypassed when arming On during the door zone full trigger output On during fault report to indicate a door is open and bypassed when arming On during a hood zone full trigger output On during fault report to indicate the hood is open and...
  • Page 9 Icon Description Text field Displays the clock, message text and feature menus On after the garage open** message has been received On after the garage closed** message has been received Remote start is active, the engine is running (with optional remote start module only) * This icon not present until the car 2 is turned on in the Setup Remote configuration menu.

  • Page 10: Using Your System

    Using your System Commands and Confirmations Commands, basic or advanced, are used to activate system fea- tures and are performed by pressing one of the command buttons. Basic commands control the most often used security features while advanced commands control more specialized features and request reports.

  • Page 11: Responder Lc Command Table

    Responder LC Command table Direct Access Level Button LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Arm/Lock Silent Arm Sensor Sensor Silent Full Silent (Panic) Bypass Disarm/Unlock Silent Disarm Remote Valet Car Finder Remote Start*/ Aux 1/4** Aux/Trunk AUX 1 AUX 2 AUX 3 AUX 4...

  • Page 12: Basic Commands (Direct Access)

    Basic Commands (Direct Access) Press and release 6:30 The alarm arms, doors lock (if connected), and the siren chirps and parking lights fl ash once. The text and beeps play ARMED to confi rm and the system status icons update. If valet mode* is on, the doors lock and the text and tone play.

  • Page 13: Aux/Trunk

    AUX/Trunk Press and hold The trunk opens (if connected) when this button is pressed for 2 sec- onds. The text and tones play to confirm. TRUNK Remote Start /AUX 1/ AUX 4 Press and release Remote Start*** Activates (or if on, deactivates) the remote starter. The engine and parking lights turn on or off accordingly.

  • Page 14: Advanced Commands: (Level 1)

    Advanced Commands: (Level 1) Press and release the button 1 time. level 1 Silent Arm Press and release The alarm arms, doors lock (if connected), and the parking lights fl ash once. The text plays to confi rm and the system status SILENT ARMED icons update.

  • Page 15: Advanced Commands: (Level 2)

    Advanced Commands: (Level 2) Press and release the button 2 times. Sensor Bypass level 2 Press and release The parking lights fl ash each time this command is received to indicate the Sensor bypass type. 2 fl ashes indicates sensor Warn-away zones are bypassed.

  • Page 16: Advanced Commands: (Level 3)

    Advanced Commands: (Level 3) Press and release the button 3 times. Sensor Silent Arm* level 3 Press and release The alarm arms, doors lock, the siren chirps and parking lights fl ash 3 times. The text and beeps play to confi rm and the SENSOR SILENT ARM system and siren status icons update.

  • Page 17: Alarm Report

    Alarm Report* Press and hold the button Requests a report of the most recent triggers and temporarily displays it in the text fi eld. The report clears when the ignition is turned on. Alarm Features * See in online guide. ©...

  • Page 18: Advanced Commands: (Level 4)

    Advanced Commands: (Level 4) Press and release the button 4 times. Full Silent Arm* level 4 Press and release The alarm arms, doors lock, and the siren chirps and parking lights fl ash 4 times. The text and beeps play to confi rm FULL SILENT ARM and the system and siren icons update.

  • Page 19: 1-Way Companion Remote Control

    1-way Companion Remote Control Internal Antenna Transmit LED Command Buttons Press and Release Shift (Press/release Press/Hold Action “AUX” first) for 2 secs. Button Silent Arm Arm and Panic Disarm Silent Disarm No Function Shift* Sensor Bypass Trunk release Remote Start**/AUX No Function No Function 1-4***...

  • Page 20: Battery Information (Responder Lc)

    Battery Information (Responder LC) The Responder LC remote control is powered by an internal recharge- able battery that can be serviced only through an authorized Directed dealer. Warnings! NEVER connect the supplied AC adapter to products other than the Responder LC remote con- trol.

  • Page 21: Patent Information

    Patent Information This product is covered by one or more of the following United States patents: Remote Start Patents: 5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053; 7,483,783 Vehicle Security Patents: 5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591; 5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667; 5,952,933;...

  • Page 22: Government Regulations

    Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 23: Additional Information

    Additional information Interference All radio devices are subject to interference which could affect proper performance. Upgrades and Batteries Any upgrades to this product and/or installation of batteries must be performed by an authorized dealer. Do not attempt to perform any unauthorized modifications to this product.

  • Page 24: Limited Lifetime Consumer Warranty

    Limited lifetime consumer warranty Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereaf- ter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was profession-...
  • Page 25 ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE UNIT.
