Since its inception, Directed has had one
purpose, to provide consumers with the fin-
est vehicle security and car stereo prod-
ucts and accessories available. The recipient
of nearly 100 patents and Innovations Awards
in the field of advanced electronic technology.
Quality Directed products are sold and ser-
viced throughout North America and around
the world.
Call (800) 274-0200 for more information
about our products and ser vic es.
© 2012 Directed. All rights reserved.
www.automatecarsecurity.com
Vista, CA 92081
Directed is committed to delivering world-
class quality products and services that excite
and delight our customers.
QRG5104A ML 2012-12
O W N E R' S
Vehicle Security System
G U I D E
MOD EL
5104A
Advertisement
Table of Contents
Related Manuals for Auto Mate 5104A
Summary of Contents for Auto Mate 5104A
- Page 1 © 2012 Directed. All rights reserved. QRG5104A ML 2012-12 www.automatecarsecurity.com MOD EL Vista, CA 92081 Directed is committed to delivering world- O W N E R’ S G U I D E 5104A class quality products and services that excite and delight our customers.
-
Page 2: What You Get
Congratulations Congratulations on the purchase of your state-of-the-art remote start and security system. Reading this Owner’s Guide prior to using your system will help maximize the use of your system and its many fea- tures. Please visit: www.automatecarsecurity.com – For general and additional guide information. - Page 3 Government Regulations and Safety information Read the Government Regulations and Warning! Safety First sections of this manual prior to operating this system. Warning! Failure to heed this information can result in death, personal injury or property damage and may also result in the illegal use of the system beyond its intended purpose.
-
Page 4: Table Of Contents
Contents Remote Control ....................2 Battery Information ....................3 Battery Disposal .................. 3 Using your System ....................4 Remote Control Command table ............4 Basic Commands (Direct Access) ................5 Arm ....................5 Disarm ....................5 Trunk Release ..................5 Remote Start .................. -
Page 5: Remote Control
Remote Control Internal Antenna Transmit LED Command Buttons Feature Description Internal Antenna Used for transmitting information Transmit LED Active when transmitting information Command buttons (4) Used to perform arming, disarming, auxiliary channel and remote start commands Control Center Control button Antenna Status LED The Control Center, typically located on the upper part of the front... -
Page 6: Battery Information
The In-vehicle system antenna. The Status LED, as a visual indicator of the system’s status. The Control button, for placing the system into Valet Mode* and to perform the Emergency Override** operation. Remote and System Operations * See in online guide. Alarm Features ** See in online guide. -
Page 7: Using Your System
Using your System Remote Control Command table Press and Release Shift (Press/release Press/Hold Action “AUX” first) for 2 secs. Button Silent Arm Arm, Panic and Car Finder Disarm Silent Disarm No Function Shift* Sensor Bypass Trunk release Remote Start Runtime Reset No Function * Advanced commands are performed by pressing and releasing the button... -
Page 8: Basic Commands (Direct Access)
Basic Commands (Direct Access) Press and release The alarm arms, doors lock (if connected), and the siren chirps and parking lights flash once. If Valet mode* is On, the doors lock without siren chirps, the alarm is disabled. Exit Valet mode to arm the alarm normally. -
Page 9: Remote Start
Remote Start Press and release Activates (or if On, deactivates) the remote starter. The engine and parking lights turn On, or the engine and parking lights turn Off ac- cordingly. If a Remote start configuration issue prevents the engine from starting, the parking lights flash a Remote Start fault report*** to identify the fault. -
Page 10: Advanced Commands
Advanced Commands Press and release the once, followed quickly (within 2 seconds) by pressing and releasing another command button. Silent Arm Press and release , then press and release The alarm arms, doors lock (if connected), and the parking lights flash once. -
Page 11: Runtime Reset
Runtime reset Press and release , then press and release If more time is needed while remote start is active, runtime reset will reset the runtime counter to the pre-programmed setting. Note Remote Start must be On to use this feature. Alarm Features * See in online guide. -
Page 12: Government Regulations
Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 13: Warning! Safety First
Warning! Safety First Please read the safety warnings below before proceeding. Improper use of the product may be dangerous or illegal. Installation Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. If you have any questions, ask your retailer or contact Directed directly at 1-800-753-0600. - Page 14 Before remote starting a manual transmission vehicle, be sure to: Leave the vehicle in neutral and be sure no one is standing in front or behind the vehicle. Only remote start on a flat surface Have the parking brake fully engaged WARNING! It is the responsibility of the owner to ensure the parking/emer- gency brake properly functions.
-
Page 15: Interference
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPER- ATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMME- DIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED Directed DEALER TO REPAIR OR DISCONNECT THE IN- STALLED REMOTE START MODULE. -
Page 16: Limited Lifetime Consumer Warranty
Limited lifetime consumer warranty Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereaf- ter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was profession-... - Page 17 ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE UNIT.
