- Page 1 Arecont Vision MegaDome Installation Manual 0 | P a g e...
- Page 2 Arecont Vision MegaDome Installation Manual MegaDome™ Installation Manual Inside the box: Mounting the Camera: Arecont Vision MegaDome Remove camera and hardware from the Mounting template box. C. Magnetic core Using the Mounting template, prepare the D. Pack of four (4) wood screws and four (4)
- Page 3 Arecont Vision MegaDome Installation Manual Run Ethernet cable through the hole on the bottom of the camera (Image 3) and plug it into the RJ45 port. NOTE: If the camera will be powered via PoE, please skip to step 6.
- Page 4 Arecont Vision MegaDome Installation Manual Reference Image 5 for proper positioning of Adjusting the Tilt, Pan, Z-axis (yaw) and Focus: the magnetic core. To adjust the tilt, use a #1 Phillips screwdriver If you are using the side conduit opening,...
- Page 5 Arecont Vision MegaDome Installation Manual To adjust back focus, loosen the two (2) set screws with the appropriate Allen key as shown Image 8 (only one of two screw holes shown). Adjust the silver back focus ring as needed and tighten down the set screws.
- Page 6 Arecont Vision MegaDome Installation Manual MegaDome™ Pendant Installation Instructions Inside the box: Top shield Pendant Mount C. Mounting template D. Pack of four (4) machine screws Pack of four (4) small machine screws Pack of four (4) wood screws and four (4)
- Page 7 Arecont Vision MegaDome Installation Manual MegaDome™ Wall Mount Installation Instructions Inside the box: Top shield and Wall mount Mounting template C. Pack of four (4) machine screws D. Pack of four (4) wood screws and four (4) dry wall anchors...
- Page 8 Arecont Vision MegaDome Installation Manual MegaDome™ Junction Box Adapter Installation Instructions Inside the box: Junction Box Adapter Pack of four (4) machine screws C. Pack of four (4) wood screws and four (4) dry wall anchors D. Large round rubber gasket...
- Page 9 Arecont Vision MegaDome Installation Manual MegaDome™ Flush Mount Adapter Installation Instructions Inside the box: Screw the “lever screws” until the FMA is snuggly installed, as shown in Image 19. The Flush Mount Adapter “Support Arm” will ride down the screw to G.
- Page 10 Arecont Vision MegaDome Installation Manual MegaDome™ Electrical Box Adapter Installation Instructions Inside the box: Electrical Box Adapter Pack of four (4) machine screws Not included but needed: • #2 Phillips head screw driver • Common Electrical Box, such as single gang box, double gang box or square electrical box.
- Page 11 Arecont Vision MegaDome Installation Manual MegaDome™ Pole Mount Adapter Installation Instructions Inside the box: 53. Run Ethernet Cable and outside power cable (if necessary) through the Compress Fittings Pole Mount Adapter and MegaDome™ Wall Mount. 2x Compress Fittings C. 2x Small Steel Straps 54.
- Page 12 Arecont Vision MegaDome Installation Manual MegaDome™ Corner Mount Adapter Installation Instructions Inside the box: Corner Mount Adapter 2x Compression Fittings C. Pack of four (4) machine screws D. 2x Packs of four (4) wood screws and four (4) dry wall anchors Not included but needed: •...
- Page 13 Arecont Vision MegaDome Installation Manual MegaDome™ I/O Cable Connection Inside the box: connector as shown in image 31. NOTE: The connection is a little stiff so be sure to apply I/O Cable enough pressure to connect it; using a flat...
- Page 14 Arecont Vision MegaDome Installation Manual Image 31 Image 31.1 Image 31.2 Connect Here Do NOT Connect Here 13 | P a g e...
- Page 15 Arecont Vision MegaDome Installation Manual MegaDome™ Heater Accessory Inside the box: Screw the heater board to the standoffs as shown in Image 34 Heater Two (2) screws Not included but needed: • #1 Phillips head screw driver Image 33 Image 32...
- Page 16 Arecont Vision MegaDome Installation Manual MegaDome™ Focus Tool Accessory Inside the box: Focus Tool NOTE: Focus Tool is a small piece of bubble which has same material and property as bubble’s, including thickness, curvature and other optical performance. Image 36...
- Page 17 Arecont Vision MegaDome Installation Manual 16 | P a g e...
