- Page 1 ® Arecont Vision MegaDome Installation Manual 0 | P a g e...
- Page 2 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Installation Manual Inside the box: Mounting the Camera: ® Arecont Vision MegaDome Remove camera and hardware from the box. Mounting template C. AC & DC Power cable Using the Mounting template, prepare the D.
- Page 3 ® Arecont Vision MegaDome Installation Manual Run Ethernet cable through the hole on the bottom of the camera (Image 3) and plug it Align the holes in the camera with the into the RJ45 port. NOTE: If the camera will prepared holes on the mounting surface.
- Page 4 ® Arecont Vision MegaDome Installation Manual Adjusting the Tilt, Pan, Z-axis (yaw): To adjust the tilt, use a #1 Phillips screwdriver to loosen the screw on the side of the plastic lens bracket 1/4 turn (Image 5). CAUTION: Do not remove the screw!
- Page 5 ® Arecont Vision MegaDome Installation Manual Adjusting the Focus and Zoom: If the “Enable Auto Focus after zoom” option is checked as shown in image 7, the focus To adjust Focus or Zoom, open camera web will automatically be adjusted when zoom is interface and click the “Focus”...
- Page 6 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Pendant Mount (MD-CMT) Installation Instructions Inside the box: Top shield Pendant Mount C. Mounting template D. Pack of four (4) machine screws Pack of four (4) small machine screws Pack of four (4) wood screws and four (4)
- Page 7 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Wall Mount (MD-WMT2) Installation Instructions Caution: MD-WMT2 only fits with SV-JBA and SV-EBA but not with the older MD-JBA and MD-EBA! Inside the box: Wall mount Top shield C. Mounting template D.
- Page 8 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Wall Mount Cap (MD-CAP) Installation Instructions Inside the box: Wall Mount Cap (MD-CAP) Pack of four (4) machine screws MD-CAP Not included but needed: • 1½” NPT Pipe nipple 1 ½” Coupling •...
- Page 9 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Junction Box Adapter (MD-JBA) Installation Instructions Caution: Remove Junction Box and hardware from the ® MD-JBA only fits with MegaDome 2 and MD-CMT but not with MD-WMT2! Inside the box: Junction Box Adapter Pack of four (4) machine screws C.
- Page 10 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Junction Box Adapter (SV-JBA) for MD-WMT2 Installation Instruction Caution: SV-JBA only fits with MD-WMT2 but not with ® MegaDome 2 and MD-CMT! Inside the box: Junction Box Adapter Pack of four (4) machine screws C.
- Page 11 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Flush Mount Adapter (MD-FMA) Installation Instructions Inside the box: Screw the “lever screws” until the FMA is snuggly installed, as shown in Image 21. The Flush Mount Adapter “Support Arm” will ride down the screw to G.
- Page 12 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Electrical Box Adapter (MD-EBA) Installation Instructions Caution: Attach Dome to Electrical Box Adapter as shown in Image 25. Please reference ® MD-EBA fits with MegaDome 2 and MD-CMT but “Mounting the Camera”, if needed.
- Page 13 ® Arecont Vision MegaDome Installation Manual ® MegaDome Electrical Box Adapter (SV-EBA) for SV-WMT2 Installation Instructions Caution: SV-EBA fits with MD-WMT2 but not with Attach Dome to Electrical Box Adapter as ® shown in Image 27. Please reference MegaDome 2 and MD-CMT! “Mounting the Camera”, if needed.
- Page 14 ® Arecont Vision MegaDome Installation Manual ® MegaDome Pole Mount Adapter (MD-PMA) Installation Instructions Inside the box: Run Ethernet Cable and outside power cable (if necessary) through the Compress Fittings ® Pole Mount Adapter and MegaDome Wall Mount, MD-WMT2. 2x Compress Fittings C.
- Page 15 ® Arecont Vision MegaDome Installation Manual ® MegaDome Corner Mount Adapter (MD-CRMA) Installation Instructions Inside the box: Corner Mount Adapter 2x Compression Fittings C. Pack of four (4) machine screws D. 2x Packs of four (4) wood screws and four...
- Page 16 ® Arecont Vision MegaDome Installation Manual ® MegaDome I/O Cable Connection Inside the box: I/O Cable Connector Image 34 Image 35 Not included but needed: NOTE: Both the input and the output are electrically • Flat head screw driver isolated from the rest of the camera’s ®...
- Page 17 ® Arecont Vision MegaDome Installation Manual ® MegaDome 2 Heater MD2-HK Accessory Inside the box: With the heater element protruding out of the camera, align the two (2) holes on the heater Heater board with the two holes on gimbal base Two (2) screws shown in Image 38.
- Page 18 ® Arecont Vision MegaDome Installation Manual 17 | P a g e...
