Overvoltage
dataline protection
UPS Output
Rated output voltage
C. 1000 R (S) – C. 3000 R (S)
C. 6000 R
Nominal frequency
C. 1000 R (S) – C. 3000 R (S)
C. 6000 R
Voltage waveform
Connection
Current Crest Ratio
Overload behaviour in battery mode
C. 1000 R (S) – C. 3000 R (S)
C. 6000 R
Overload behaviour with existing mains
C. 1000 R (S) – C. 3000 R (S)
RJ11 (phone, fax, modem)
RJ45 (Ethernet 10/100 MBit/s)
220 / 230 / 240 Vac ± 2 %
220 / 230 / 240 Vac ± 1 %
(configuration via software
"CompuWatch")
50 Hz / 60 Hz ± 0.2 %
50 Hz / 60 Hz ± 0.1 %
(depending on mains)
Pure sine wave
Harmonic distortion:
≤ 4 % THD (linear load)
≤ 7 % THD (non-linear load)
Non-heating appliance connectors
3:1
up to 105 % ± 5 % continuous;
> 105 % ± 5 % – < 150 % ± 5 %
for 25 s;
150 % ± 5 % for 200 ms
up to 105% continuous;
> 105 % for 10 s
up to 105 % ± 5 % continuous;
> 105 % ± 5 % – < 150% ± 5 %
for 30 s;
150 % ± 5 % for 300 ms
Then automatic inverter to
Bypass in < 4 ms (switches
back when overload damps =
Load < 90 %))
