Summary of Contents for Wildgame LO8
- Page 1 Invisible Infrared Digital Scouting Camera User’s Manual Model # LO8...
- Page 2 Includes User Manual USB Cable 2 - Bungee Cords Flextime Player Camera Unit Software NOTE: Flextime Player Software is optional. Flextime files can be played by using most media players. page 1...
- Page 3 Features RESOLUTION MAX: 8 MP FLASH 60 High Intensity Invisible IR LED’s FLASH RANGE up to 70 feet SENSOR Passive Infrared Sensor (PIR) Detects Motion and Heat SENSOR RANGE up to 75 feet JPEG - Digital Still / AVI - Digital Video IMAGE FORMAT MEMORY up to 32GB SD Card (not included and required)
-
Page 4: Installing Batteries
Installing Batteries With the camera facing up, open With the bottom of the camera the battery compartment at the towards you, load 6 AA batteries with bottom of the camera by turning the positive ends towards you in the them to the left. left battery chamber and load 6 AA batteries with the positive ends towards you in the right battery... - Page 5 Close battery compartment cover Load SD memory card (up to 32GB not by turning them to the right. into the SD card slot with the included) connectors facing down. Open the door at the bottom of TIPS: the camera by unlatching the Make sure the SD Card is unlocked (small locking tabs.
-
Page 6: Test Mode
Test Mode Power On LCD Ready Mode: The camera will To turn the unit ON press and release automatically enter Ready Mode if a the power button. button is not pressed for greater than 30 seconds. The status lights will 00:00 PM 00/00/00 TIME / DATE LOCATION... -
Page 7: Power Save
Power Save Date/Time To change Date & Time, enter After 30 seconds without any buttons MENU and press the UP,DN,L or being pushed, the LCD will turn off and R buttons to navigate to the DATE camera enters into Power Save or &... - Page 8 Location Image Type:Still To change Location, enter MENU To change Image Type, enter and press the UP,DN,L or R MENU and press the UP,DN,L or buttons to navigate to the R buttons to navigate to the LOCATION icon and press OK. Image Type icon and press OK.
- Page 9 Image Type:Video Trigger To change Image Type, enter To change Trigger, enter MENU MENU and press the UP,DN,L or and press the UP,DN,L or R R buttons to navigate to the buttons to navigate to the Trigger Image Type icon and press OK. icon and press OK.
-
Page 10: Pir Sensitivity
PIR Sensitivity Active Time To change PIR Sensitivity, enter To change the Active Time, enter MENU and press the UP,DN,L or MENU and press the UP,DN,L or R buttons to navigate to the PIR R buttons to navigate to the Sensitivity icon and press OK. - Page 11 FLEXTIME selected Flextime period: Camera is inactive before and after Flextime periods. Flextime is active twice a day. 1. 15 min before Sunrise 15 MINUTES 15 MINUTES AFTER BEFORE to 1 hour after Sunrise. FLEX FLEX SUNSET SUNRISE INACTIVE TIME TIME INACTIVE 2.
- Page 12 Flextime +™ Delay To change Flextime™, enter To change the Delay, enter MENU MENU and press the UP,DN,L or and press the UP,DN,L or R R buttons to navigate to the buttons to navigate to the Delay Flextime™ icon and press OK. icon and press OK.
-
Page 13: Playback: Videos
Playback: Stills Playback: Videos To view your images, enter MENU To view your videos, enter MENU and press the UP,DN,L or R and press the UP,DN,L or R buttons to navigate to the buttons to navigate to the Playback icon and press OK. Playback icon and press OK. - Page 14 View Assist To use View Assist, enter MENU and press the UP,DN,L or R buttons to navigate to the View Assist icon and press OK. DATE & TIME LOCATION IMAGE TYPE TRIGGER PIR SENSITIVITY ACTIVE TIME FLEXTIME ™ DELAY BACK PLAY BACK VIEW ASSIST VIEW ASSIST...
-
Page 15: Power Off
LCD screen and then external power port. You must open the weather resistant cover and use a depress and hold the power Wildgame Innovations 6 Volt camera button until the LCD turns off. battery accessory. Image Stamp Pictures Display:... - Page 16 Mounting When mounting to a tree, first latch the 2 bungee cords through the mounting holes on the left or right side of the camera. Then, stretch the cords around the tree and latch the other ends of the Adjustable sides to fit almost any size tree. bungee cords through the mounting holes on the opposite side of the camera.
- Page 17 Important Once you connect the camera to your computer via the USB cable/ports, the camera will then draw power from the computer. When completing the viewing, transfer- ring, copying or deletion of images, please make sure that you DISCONNECT THE USB CABLE FROM BOTH THE CAMERA AND THE COMPUTER, as you will not be able to power the camera OFF until you do so.
-
Page 18: Retrieving Images
Retrieving Images (SD Card in Camera) Method 1: Leave SD card in camera be listed. The computer will recognize the camera as Removable Disk. Please select A. First, make sure that the camera is Removable Disk from this menu (or double powered OFF. - Page 19 Retrieving Images (SD Card reader) Method 2: Remove SD card and use card left of your screen and select “Computer”. The summary view will then be illustrated reader on the right hand side of the window where A. First, remove the SD Card from the by the “Devices with Removable Storage”...
-
Page 20: Warranty
Warranty DISCLAIMERS WGI Innovations, LTD is not responsible for damage, expense or injury caused by the unauthorized use of, alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products. WARRANTY You must register your product warranty online at www.wildgameinnovations.com. Follow the on screen directions to complete the process. - Page 21 FCC CE FCC STATEMENT Product Name: Game Trail Camera Trade Name: Wildgame Innovations Model# LO8 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two criteria: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 22 602 Fountain Parkway Grand Prairie, TX 75050 800.847.8269 “Wildgame Innovations” and the “Button Logo” are TM trademarks of Wildgame Innovations, LLC. “Sport Responsible” , “Redux” and “Flextime” are TM trademarks of WGI Innovations, LTD.
