- Page 1 Infrared Digital Scouting Camera User’s Manual Model # t5i20...
- Page 2 Includes Camera Unit 2 - Bungee Cords User Manual page 1...
- Page 3 Features MAX: 5 MP RESOLUTION 18 High Intensity Infrared LED’s FLASH up to 55 feet FLASH RANGE Passive Infrared Sensor (PIR) Motion and Heat SENSOR up to 60 feet SENSOR RANGE JPEG - Digital Stills/ AVI-Digital Video IMAGE FORMAT up to 32GB SD Card (not included and required) MEMORY Class 4 and above recommended High (5 MP)
-
Page 4: Installing Batteries
Installing Batteries Open the door at the bottom of the camera by unlatching the locking tabs. Illustration B With the bottom of the camera to- wards you, Make sure to insert the batteries into the camera with the positive ends towards you where marked positive and the negative ends towards you where marked negative. - Page 5 Close battery compartment cover. Load SD memory card (up to 32GB To latch the cover simply pull the not included) into the SD card slot latch slightly to the left as you close with the connectors facing down. the battery compartment cover. IMPORTANT: Make sure the camera is powered off before removing or installing an SD card.
-
Page 6: Test Mode
Power On Test Mode LCD Ready Mode: The camera will To turn the unit ON press and re- automatically enter ready mode if a lease the power button. button is not pressed for greater than 45 seconds. The status light will illu- minate during these 45 seconds. -
Page 7: Power Save
Setting Time Power Save After 45 seconds without any buttons To change date and time, start by being pushed, the LCD will turn off pressing and release the center and camera enters into Power Save navigation button to set the hour. or Ready Mode. -
Page 8: Setting Date
Setting Date Photos Press the center navigation but- Press and release the center navi- ton after setting the minute to gation button to choose Photos. change the Date. The number displayed is the num- ber of photos on your SD card. This Ready Clock is not a programmable mode for... - Page 9 Image Press the center navigation button Press the center navigation button while PIR is selected. The high- while Image is selected. The high- lighted option will be blinking. lighted option will be blinking. Ready Clock Date Photos Image Still Video Resolution Active 24Hr...
- Page 10 Resolution Active Press the center navigation button Press the center navigation button while Resolution is selected. The while PIR Active is selected. The 0432 highlighted option will be blinking. highlighted option will be blinking. Date Ready Photos Clock Image Still Video Date Photos...
-
Page 11: Power Off
Delay Power Off Press the center navigation button To turn the unit off, first wake up while Delay is selected. The high- the LCD screen and then depress and hold the power button until lighted option will be blinking. the LCD turns off. Ready Clock Date... -
Page 12: Image Stamp
Image Stamp Mounting Pictures Display: When mounting to a tree, first latch the 2 bungee cords through the mounting holes on the left or right side of the camera. Then, stretch the cords around the tree and latch the other ends of the bungee cords through the mounting holes on the opposite side of the camera. - Page 13 Important The directions as contained herein assume that you are using a Microsoft operat- ing system and not Linux or a Mac-based operating system. Even said, there may be slight variations in your process based on the specific version of the operation system that you are using as well as the predefined user preference for each computer.
-
Page 14: Retrieving Images
Retrieving Images (SD Card Reader) Method 1: Remove SD card and use card F. If your computer does not automatically reader launch the AutoPlay window recognizing the A. First, remove the SD Card from the cam- Removable Disk (the SD Card), then you will era unit itself by pressing on it to where it need to go to the “Start Menu”... - Page 15 page 14...
-
Page 16: Warranty
Warranty DISCLAIMERS WGI Innovations, LTD. is not responsible for damage, expense or injury caused by the unauthorized use of, alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products. WARRANTY For the warranty to be in effect, you MUST completely fill out and mail the warranty card along with your proof of purchase to WGI Innovations within (14) days after the date of purchase. - Page 17 FCC STATEMENT Product Name: Game Trail Camera Trade Name: Wildgame Innovations Model# t5i20 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two criteria: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 18 602 Fountain Parkway Grand Prairie, TX 75050 800.847.8269 “Wildgame Innovations” and the “Button Logo” are TM trademarks of Wildgame Innovations, LLC. “Sport Responsible” is TM trademarks of WGI Innovations, LTD.
