Summary of Contents for Wildgame W5ECA
- Page 1 Infrared Digital Scouting Camera User’s Manual Model # W5ECA...
- Page 2 Includes User Manual USB Cable 2 - Bungee Cords Flextime Player Camera Unit Software NOTE: Flextime Player Software is optional. Flextime files can be played by using most media players. page 1...
- Page 3 Features RESOLUTION MAX: 5 MP FLASH 24 High Intensity Infrared LED’s FLASH RANGE up to 60 feet SENSOR Passive Infrared Sensor (PIR) Motion and Heat SENSOR RANGE up to 60 feet IMAGE FORMAT JPEG - Digital Still / AVI - Digital Video MEMORY up to 64GB SD Card (not included) 5-PIN Mini USB style - included...
-
Page 4: Installing Batteries
Installing Batteries Open the door at the bottom of the camera by unlatching the locking tabs. Open Illustration A With the camera facing open, open the battery compartment cover by sliding the latch to the left. (Illustration A and B) Illustration B page 3... - Page 5 Close battery compartment cover. To latch the cover simply pull the latch slightly to the left as you close the With the bottom of the camera battery compartment cover. towards you, Make sure to insert the batteries into the camera with the positive ends towards you where marked positive and the negative ends towards you where marked negative.
-
Page 6: Test Mode
Power On Test Mode LCD Ready Mode: The camera will To turn the unit ON press and release the power button. automatically enter Ready Mode if a button is not pressed for greater than 30 seconds. The status lights will illuminate for a total of 2 minutes. -
Page 7: Power Save
Power Save Setting Time After 30 seconds without any buttons To change date and time, start by being pushed, the LCD will turn off and pressing and release the center camera enters into Power Save or navigation button to set the hour. Ready Mode. -
Page 8: Setting Date
Setting Date Location Press the center navigation button Press the center navigation button after setting the minute to change the while Location is selected. The first Day. character will be blinking. Time/Date Time/Date Location Location Trigger PIR Mode Flextime Both PIR Mode Flextime Both... - Page 9 Trigger Flextime Press the center navigation button Press the center navigation button while Flextime is selected. The while Trigger is selected. The highlighted option will be blinking. highlighted option will be blinking. Time/Date Time/Date Location Location PIR Mode Flextime Both Trigger PIR Mode Flextime...
- Page 10 FLEXTIME selected Flextime period: Camera is inactive before and after Flextime periods. Flextime is active twice a day. 1. 15 min before Sunrise 15 MINUTES 15 MINUTES AFTER BEFORE to 1 hour after Sunrise. SUNSET FLEX FLEX SUNRISE INACTIVE TIME TIME INACTIVE 2.
- Page 11 PIR Mode PIR Active Press the center navigation button Press the center navigation button while PIR Mode is selected. The while PIR Active is selected. The highlighted option will be blinking. highlighted option will be blinking. Time/Date Time/Date Location Location Trigger PIR Mode Flextime...
-
Page 12: Pir Sensitivity
PIR Sensitivity Picture Press the center navigation button Press the center navigation button while PIR Sense is selected. The while Picture is selected. The highlighted option will be blinking. highlighted option will be blinking. Time/Date Time/Date Location Location PIR Mode Flextime Both Trigger... - Page 13 Resolution Delay Press the center navigation button Press the center navigation button while Resolution is selected. The while Delay is selected. The highlighted option will be blinking. highlighted option will be blinking. Time/Date Time/Date Location Location PIR Mode Flextime Both PIR Mode Flextime Both...
-
Page 14: Power Off
Power Off Power Port WGI Cameras come standard with an To turn the unit off, first wake up the external power port. You must open LCD screen and then depress and hold the weather resistant cover and use a the power button until the LCD turns Wildgame Innovations 6 Volt camera off. - Page 15 Important Mounting Once you connect the camera to your computer via the When mounting to a tree, first latch USB cable/ports, the camera will then draw power from the 2 bungee cords through the the computer. When completing the viewing, transfer- ring, copying or deletion of images, please make sure mounting holes on the left or right that you DISCONNECT THE USB CABLE FROM BOTH...
-
Page 16: Retrieving Images
Retrieving Images (SD Card in Camera) Method 1: Leave SD card in camera be listed. The computer will recognize the camera as Removable Disk. Please select A. First, make sure that the camera is Removable Disk from this menu (or double powered OFF. - Page 17 Retrieving Images (SD Card reader) Method 2: Remove SD card and use card left of your screen and select “Computer”. The summary view will then be illustrated reader on the right hand side of the window where A. First, remove the SD Card from the by the “Devices with Removable Storage”...
-
Page 18: Warranty
Warranty DISCLAIMERS WGI Innovations, LTD. is not responsible for damage, expense or injury caused by the unauthorized use of, alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products. WARRANTY You must register your product warranty online at www.wildgameinnovations.com. Follow the on screen directions to complete the process. - Page 19 Product Name: Game Trail Camera Trade Name: Wildgame Innovations Model# W5ECA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two criteria: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 20 602 Fountain Parkway Grand Prairie, TX 75050 800.847.8269 “Wildgame Innovations” and the “Button Logo” are TM trademarks of Wildgame Innovations, LLC. “Sport Responsible” , “Redux” and “Flextime” are TM trademarks of WGI Innovations, LTD.
