Summary of Contents for Wildgame N2E
- Page 1 Infrared Digital Scouting Camera User’s Manual Model # N2E...
-
Page 2: Components View
Includes User Manual USB Cable 2 - Bungee Cords Flextime Player Camera Unit Software NOTE: Flextime Player Software is optional. Flextime files can be played by using most media players. page 1... -
Page 3: Features
Features RESOLUTION 2 MP FLASH 18 High Intensity Infrared LED’s FLASH RANGE up to 45 feet SENSOR Passive Infrared Sensor (PIR) Motion and Heat SENSOR RANGE up to 60 feet IMAGE FORMAT JPEG - Digital Still MEMORY up to 32GB SD Card (not included) 5-PIN Mini USB style - included IMAGE RESOLUTION POWER SUPPLY... -
Page 4: Installing Batteries
Installing Batteries Open the door at the bottom of the camera by unlatching the locking tabs. Illustration A With the camera facing open, open the battery compartment cover by sliding the latch to the left. (Illustration A and B) Illustration B page 3... - Page 5 Close battery compartment cover. To latch the cover simply pull the latch With the bottom of the camera slightly to the left as you close the towards you, load two C-cell batteries battery compartment cover. with the positive ends towards you in the left battery chamber and load two C-cell batteries with the negative ends towards you in the right battery...
-
Page 6: Power On
Power On Test Mode LCD Ready Mode: The camera will To turn the unit ON press and release automatically enter Ready Mode if a the power button. button is not pressed for greater than 30 seconds. The status lights will illuminate for a total of 2 minutes. -
Page 7: Power Save
Power Save Setting Time To change date and time, start by After 30 seconds without any buttons pressing and release the center being pushed, the LCD will turn off and navigation button to set the hour. camera enters into Power Save or Ready Mode. -
Page 8: Setting Date
Setting Date Location Press the center navigation button Press the center navigation button after setting the minute to change the while Location is selected. The first Day. character will be blinking. Ready Ready POWER POWER Time/Date Time/Date Location Location Trigger Trigger PIR Mode Flextime... -
Page 9: Trigger/Flextime
Trigger Flextime Press the center navigation button Press the center navigation button while Trigger is selected. The while Flextime is selected. The highlighted option will be blinking. highlighted option will be blinking. POWER POWER OWER POWER Press the left or right navigation Press the left or right navigation button to move to different options. -
Page 10: Flextime Selected Interval
FLEXTIME™ Time Lapse Technology FLEXTIME selected Camera is inactive before and after Flextime periods. Flextime period: Flextime is active twice a day. 1. 15 min before Sunrise 15 MINUTES 15 MINUTES AFTER BEFORE to 1 hour after Sunrise. SUNSET FLEX FLEX SUNRISE INACTIVE... -
Page 11: Pir Active/Delay
PIR Active Delay Press the center navigation button Press the center navigation button while PIR Active is selected. The while Delay is selected. The highlighted option will be blinking. highlighted option will be blinking. POWER POWER POWER POWER Press the left or right navigation Press the left or right navigation button to move to different options. -
Page 12: Power Off
To turn the unit off, first wake up the external power port. You must open LCD screen and then depress and hold the weather resistant cover and use a the power button until the LCD turns Wildgame Innovations 6 Volt camera off. battery accessory. Image Stamp Pictures Display:... - Page 13 Important Mounting Once you connect the camera to your computer via the When mounting to a tree, first latch USB cable/ports, the camera will then draw power from the 2 bungee cords through the the computer. When completing the viewing, transfer- ring, copying or deletion of images, please make sure mounting holes on the left or right that you DISCONNECT THE USB CABLE FROM BOTH...
-
Page 14: Retrieving Images
Retrieving Images (SD Card in Camera) Method 1: Leave SD card in camera be listed. The computer will recognize the camera as Removable Disk. Please select A. First, make sure that the camera is Removable Disk from this menu (or double powered OFF. - Page 15 Retrieving Images (SD Card reader) Method 2: Remove SD card and use card left of your screen and select “Computer”. The summary view will then be illustrated reader on the right hand side of the window where A. First, remove the SD Card from the by the “Devices with Removable Storage”...
-
Page 16: Warranty
Warranty DISCLAIMERS WGI Innovations, LTD. is not responsible for damage, expense or injury caused by the unauthorized use of, alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products. WARRANTY You must register your product warranty online at www.wildgameinnovations.com. Follow the on screen directions to complete the process. - Page 17 FCC STATEMENT Product Name: Game Trail Camera Trade Name: Wildgame Innovations Model# N2E This device complies with Part 15 of the FCC Rules. Operation is subject to the following two criteria: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 18 602 Fountain Parkway Grand Prairie, TX 75050 800.847.8269 “Wildgame Innovations” and the “Button Logo” are TM trademarks of Wildgame Innovations, LLC. “Sport Responsible” , “Redux” and “Flextime” are TM trademarks of WGI Innovations, LTD.
