- Page 1 Infrared Digital Scouting Camera User’s Manual Model # r12i20...
- Page 2 Includes T-Post Support Adjustable Strap User Manual Flextime Player Camera Unit Software NOTE: Flextime Player Software is optional. Flextime files can be played by using most media players page 1...
- Page 3 Features MAX: 12 MP Still RESOLUTION 36 High Intensity Infrared LED’s FLASH up to 70 feet FLASH RANGE Passive Infrared Sensor (PIR) Motion and Heat SENSOR up to 60 feet SENSOR RANGE JPEG - Digital Stills/ AVI-Digital Video IMAGE FORMAT up to 32GB SD Card (not included and required) MEMORY Class 4 and above recommended...
-
Page 4: Installing Batteries
Installing Batteries With the camera facing up, open the Open the door on the right of the camera and PULL the tab compartment door. towards you. Push the battery latch up to unlock. At the same time grab the battery compartment out. page 3... - Page 5 Make sure to insert the AA-cell Load SD memory card (up to 32GB not batteries based on the direction included) into the SD CARD slot with the labeled on the inside of each com- connectors facing down. partment. Match minus “-” sign with the marked negative on the battery and the plus “+”...
-
Page 6: Test Mode
Power On Test Mode LCD Ready Mode: The camera will To turn the unit ON press and re- automatically enter Ready Mode if a lease the power button. button is not pressed for greater than 30 seconds. The status lights will il- luminate for a total of 2 minutes. -
Page 7: Power Save
Setting Time Power Save After 30 seconds without any buttons To change date and time, start by being pushed, the LCD will turn off pressing and release the OK but- and camera enters into Power Save ton to set the hour. or Ready Mode. -
Page 8: Setting Date
Setting Date Location Press the OK button after setting Save the location of the area the camera was installed. This is for your reference and is op- the minute to change the Day. tional. If you do not wish to name your location skip to the next step. - Page 9 Flextime Trigger Press the OK button while Flex- This setting allows you to choose the mode in which the camera will be capturing images. time is selected. The highlighted option will be blinking. Press the OK button while Trigger is selected. The highlighted option will be blinking.
- Page 10 FLEXTIME selected Camera is inactive before and after Flextime periods. Flextime is active twice a day. Flextime period: 15 MINUTES 15 MINUTES 1. 15 min before Sunrise BEFORE AFTER SUNRISE FLEX FLEX SUNSET to 1 hour after Sunrise. INACTIVE TIME TIME INACTIVE 2.
- Page 11 PIR Active PIR Mode Press the OK button while PIR Ac- Press the OK button while PIR tive is selected. The highlighted Mode is selected. The highlighted option will be blinking. option will be blinking. POWER POWER RESET RESET Press the left or right naviga- Press the left or right naviga- tion button to move to different tion button to move to different...
-
Page 12: Pir Sensitivity
PIR Sensitivity Exposure Press the OK button while PIR Press the OK button while Expo- Sense is selected. The highlighted sure is selected. The highlighted option will be blinking. option will be blinking. POWER POWER RESET RESET Press the left or right naviga- Press the left or right naviga- tion button to move to different tion button to move to different... - Page 13 Picture/Video Resolution Press the OK button while Resolu- Press the OK button while Picture tion is selected. The highlighted is selected. The highlighted option option will be blinking. will be blinking. POWER POWER RESET RESET Press the left or right navigation Press the left or right navigation button to move to different op- button to move to different op-...
-
Page 14: Power Off
Delay Power Off Press the OK button while Delay To turn the unit off, first wake up is selected. The highlighted option the LCD screen and then depress and hold the power button until will be blinking. the LCD turns off. POWER POWER RESET... -
Page 15: Power Port
Image Stamp Power Port WGI Cameras come standard with Pictures Display: an external power port. You must open the weather resistant cover and use a Wildgame Innovations 6 Volt camera battery accessory. 087°F 08:15PM 11-12-2011 0200 A- Temperature B- Time... - Page 16 Mounting When mounting to a tree, first remove When mounting to a T-Post, first attach the clip from one end of the strap so the T-Post bracket to the camera. you can slide the strap through the slots located on the back of the cam- era.
- Page 17 Important There is also a standard 1/4”-20 tripod The directions as contained herein assume that you are using a Microsoft operating system and connector. not Linux or a Mac-based operating system. Even said, there may be slight variations in your process based on the specific version of the op- eration system that you are using as well as the predefined user preference for each computer.
-
Page 18: Retrieving Images
Retrieving Images (SD Card Reader) Method 2: Remove SD card and use card left of your screen and select “Computer”. reader The summary view will then be illustrated A. First, remove the SD Card from the cam- on the right hand side of the window where era unit itself by pressing on it to where it by the “Devices with Removable Storage”... - Page 19 page 18...
-
Page 20: Warranty
Warranty DISCLAIMERS WGI Innovations, LTD. is not responsible for damage, expense or injury caused by the unauthorized use of, alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products. WARRANTY For the warranty to be in effect, you MUST completely fill out and mail the warranty card along with your proof of purchase to WGI Innovations within (14) days after the date of purchase. - Page 21 FCC STATEMENT Product Name: Game Trail Camera Trade Name: Wildgame Innovations Model# r12i20 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two criteria: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 22 602 Fountain Parkway Grand Prairie, TX 75050 800.847.8269 “Wildgame Innovations” and the “Button Logo” are TM trademarks of Wildgame Innovations, LLC. “Sport Responsible” and “Flextime” are TM trademarks of WGI Innovations, LTD.
