BATTERY PACKS

D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-106 charger adapters.
• An AC adapter (BC-157) or the DC power cable (OPC-656).
AC adapter
(Purchased
separately)
DC power cable
(OPC-656)
(Connect with the
DC power supply;
13.8 V/at least 7 A)
31
Transceiver
Turn power OFF
Battery
pack
AD-106 charger
adapters are installed
in each slot.
IMPORTANT!:
Ensure the guide lobes
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
Lobes
Guide rails
