Display symbols

15
16
17
Fig. 2 Standard display ModuLine 300
pos. description standard display
15 time and date
16 measured room temperature
17 symbol view
Explanation of the symbols in the standard view
symbol explanation
Boiler is operating
Arrow points to the button to be operated.
Domestic hot water (DHW) operation is turned off
When button illumination is turned off (→ paragraph 6.5):
symbol explanation
Auto-operation (time program) is turned on.
Manual operation is turned on.
Boiler is turned off, freeze protection is active.
DHW operation according to paragraph 6.3.
