5 Menu 1 – Time program
5.2

Insert switching point(s)

At this function, a switching point can be
inserted in the time program.
The time program can consist of
maximum 42 switching points.
Select "Schakelpunt(en) invoegen?".
Keep pressure the button "day" and select
with the set-up button the desired day.
Keep the button "time" pressured and turn
the set-up button to set-up the desired time.
Keep pressure the button "temperature"
and select with the set-up button the
desired temperature level.
The switching point is inserted and is
graphically shown in the display.
5.3

Remove switching point(s)

With this function, switching points can be
removed from the time program.
Select "Schakelpunt(en) invoegen?"
Select, by turning the set-up button, the
switching point that must be removed.
Keep pressure the button "OK" and turn the
set-up button until "ja" appears on the
screen. The switching point is removed and
is no longer graphically shown in the
display.
5.4

Enter new time program

Here you can enter an entirely new time
program, that satisfies your specific
wishes, chapter 4 "Set-up time program".
Nefit B.V. • http://www.nefit.nl
18
Schakelpunt invoegen
21.0
16.0
Ma 07:00 18.0°C
Fig. 26 Change switching point - day
Schakelpnt verwyderen
21.0
16.0
ma 07:00
Fig. 27 Remove switching point
Technical specifications are subject to change without prior notice.
Operating manual ModuLine 300 • edition 12/2010
T2
20.0°C ja
