Brief outline

1 Brief outline
1.1

Overview buttons

Fig. 1 Overview ModuLine 300
pos. description buttons
1 cover (use the recess on the left to open the cover)
2 standard view is activated when cover is closed
3 display
4 set-up button
pos. button for basic functions
5 auto-operation (set program)
6 manual operation
7 off-function
8 information
Nefit B.V. • http://www.nefit.nl
4
4
09:18
21
3
2
14 13
1
06.01.08
5˚C
12 11 10 9
pos.
9
10
11
12
13
14
Technical specifications are subject to change without prior notice.
Operating manual ModuLine 300 • edition 12/2010
5
6
7
8
button for additional functions
menu
back
OK
temperature
time
date
