Appendix

Selected LED Display

Activity
Off Port is not selected.
On (Steady) Port is connected to an active computer.
Flashing (On and Off equal) Port is connected to an active computer and is being
accessed in Auto Scan mode.

Specifications

Function
Power Consumption 180 mW
Computer Connections 2
Port Selection Push Button Switches; Hotkeys
LEDs On Line 2 (Orange)
Selected 2 (Green)
Connectors Keyboard 1 x 6 pin mini-DIN female (PS/2 style) - Console
2 x 6 pin mini-DIN female (PS/2 style) - CPU Ports
Mouse 1 x 6 pin mini-DIN female (PS/2 style) - Console
2 x 6 pin mini-DIN female (PS/2 style) - CPU Ports
Video 1 x HDB-15 female (std. VGA/SVGA) - Console
2 x HDB-15 male (std. VGA/SVGA) - CPU Ports
Resolution Up to 1920 x 1440; DDC, DDC2, DDC2B
Scan Interval 5 Seconds
Conversion Keyboard PC/AT & PS/2
Mouse PS/2
Operating Temperature 5 - 40
Storage Temperature -20 - 60
Humidity 0 - 80% RH Non condensing
Housing Metal
Weight 420 g
Dimensions (L x W x H) 128 x 75 x 45 mm
Meaning
Specification
o
C
o
C
- 11 -
2002-09-19
