PX4i and PX6i TAGADJUST Values
Firmware
IPL
FP
To determine the TAGADJUST value
1 For Fingerprint printers, align the label with the edge of the
2 Open the printer's side door.
3 Measure the distance between the middle of the tag and the
EasyCoder Printer (PM4i, PX4i, and PX6i ) RFID User's Guide
DPI
203
300
406
203
300
406
tear bar.
For IPL printers, press the Feed button to position the label
at the start-of-print point.
point that is directly below the antenna.
Printhead
Tag
TAGADJUST Distance for PM4i Fingerprint Printers
Label Size
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
TAGADJUST
0
108
0
159
0
216
-108
0
-159
0
-216
0
Antenna
