RFID,TAGADJUST
Specifies the distance (in number of dots) the label is moved to
align the tag under the antenna and enable successful read and
write operations. The label is moved before the printer attempts
to access the tag. A negative value moves the label back, and a
positive value moves the label forward.
Note: The printer electronically prevents the media from
moving back past the printhead.
Valid values are absolute values equal to or smaller than the
maximum label length (default = 0).
Before configuring TAGADJUST, check the recommendations
for your RFID media. To determine the TAGADJUST value, use
the next tables or procedure.
PM4i TAGADJUST Values
Firmware
IPL
FP
12
DPI
203
300
406
203
300
406
EasyCoder Printer (PM4i, PX4i, and PX6i ) RFID User's Guide
Label Size
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
4x2 in
4x3 in or larger
TAGADJUST
0
100
0
148
0
200
-100
0
-148
0
-200
0
