Configure Record Settings

There are multiple ways to setup your DVR recording. They include setting up a recording schedule, triggering a
recording by motion detection and/or a sensor alarm, and manually starting the recording.

Before Record Settings

Before configuration, please make sure your DVR has been installed with HDD and has completed its initialization,
otherwise, access Menu > HDD Management to install the HDD and perform initialization first.
Note:
Please refer to Initializing HDDs for specific instructions for initializing HDD.

Initializing Record Settings

1. Click Menu > Settings > Record to access the Record Settings dialog box, shown in Figure 1.
Figure1. General Record Settings
2. Select the camera you want to configure.
Note:
connection; please select IP Cameras for configuration.
3. Configure the following settings:
•
Encoding Parameters: Set the encoding parameters to be Normal or Event.
•
Stream Type: Set the stream type to be Video or Video & Audio.
•
Resolution: Set recording at different resolution.
•
Bit Rate Type: Set the bit rate type to be Variable or Constant.
•
Video Quality: Set the video quality of recording, with 6 levels configurable.
•
Frame Rate: Set the frame rate of recording.
•
Max Bit Rate: Select or customize the maximum bit rate for recording.
4. Click the Set button under More Settings to configure more recording settings, as shown in
Figure 2.
www.cctvireland.ie
DS-7604NI-S/M, DS-7604NI-S and DS-7608NI-S models provide no analog camera
