SPECIFICATIONS AND OPTIONS

I Specifications
Specifications are measured in accordance with EIA/TIA-603.
D D General
• Frequency coverage
• Channel specing
• PLL channel step
• Frequency stability
• Number of channels
• Antenna connector
• Operating temp. range
• Power supply voltage
• Current drain (at 13.6 V) : TX high (50 W)
• Dimensions
(Projections not included) 6(W) × 2
• Weight (approx.)
D D Transmitter
• RF output power
• Modulation system
• Max. frequency deviation : ±5.0 kHz (Wide),
• Spurious emissions
• Adjacent channel power : More than 70 dB (Wide),
• Audio harmonic distortion : 3.0% typical
• Hum and noise
• Microphone impedance
D D Receiver
• Receive system
• Sensitivity (12 dB SINAD) : 0.25 µV typical
• Intermediate frequencies : 1st; 70.0 MHz, 2nd; 455 kHz
• Adjacent channel selectivity : More than 70 dB (Wide),
• Spurious response
• Intermodulation
• Hum and noise
• Audio output power
• External speaker connector: 2-conductor 3.5 (d) mm (
All stated specifications are subject to change without
15
notice or obligation.
: 400.000–430.000 MHz
430.000–450.000 MHz
450.000–480.000 MHz
480.000–512.000 MHz
: 12.5/25.0 kHz type
: 5.0, 6.25 kHz
: ±1.5 ppm*/±2.5 ppm*
* Depends on version
: Max. 32 channel
: N-type × 2 (50 Ω)
: –30°C to +60°C
(–22°F to +140°F)
: 100–120 V AC (50/60 Hz)*
220–240 V AC (50/60 Hz)*
13.6 V DC (negative ground)
* Depends on version
20.0 A typical
Max. audio 2.0 A typical
Stand-by 1.0 A typical
: 410(W) × 110(H) × 360(D) mm
(H) × 5
5 1
⁄ ⁄ (D) in
8 2
: 12 kg; 26 lb 7 oz
: 50 W
: Variable reactance frequency
modulation system
±2.5 kHz (Narrow)
: –70 dBc typical
More than 60 dB (Narrow)
(at 1 kHz, 40% deviation)
: More than 40 dB (Wide),
More than 34 dB (Narrow)
: 600 Ω (8-pin modular)
: Double conversion
superheterodyne system
More than 60 dB (Narrow)
: More than 70 dB
: More than 70 dB
: More than 40 dB (Wide),
More than 34 dB (Narrow)
: 2.5 W typical at 10% distortion
with a 4 Ω load
") 8 Ω
1 ⁄
8
I Options
• MB-77 WALL MOUNT BRACKET (p. 10)
For mounting the repeater to a wall.
• MB-78 19 INCH RACK MOUNT BRACKET (pgs. 9, 10)
For mounting the repeater into a 19 inch rack.
• HM-100N HAND MICROPHONE
• HM-100TN DTMF MICROPHONE
Hand microphone with a DTMF keypad.
• SM-25 DESKTOP MICROPHONE
• UT-109 (#01) VOICE SCRAMBLER UNIT (p. 11)
Non-rolling type (max. 32 codes).
• UT-110 (#01) VOICE SCRAMBLER UNIT (p. 11)
Rolling type (max. 1020 codes).
The scrambler systems of the UT-109 and UT-110 are not
compatible with each other.
