Summary of Contents for HAMPTON BAY Parker Ridge
- Page 1 288 272 Parker Ridge Ceiling Fan Owner’s Manual Parker Ridge Ventilador de Techo de 1,12 Manual del Propietario...
- Page 2 Parker Ridge by Hampton Bay ®...
-
Page 3: Table Of Contents
44” Parker Ridge Thank you for purchasing our ceiling fan. This product has been manufactured with the highest standards of safety and quality. Ceiling Fan by Hampton Bay Date Purchased Table of Contents Store Purchased Safety Rules ....1 288-272 UL Model No. -
Page 4: Safety Rules
Safety Rules - Read and Save These Instructions To reduce the risk of electric shock, insure electricity has been turned off After making electrical connections, spliced conductors should be turned at the circuit breaker or fuse box before beginning. upward and pushed carefully up into outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding All wiring must be in accordance with the National Electrical Code conductor on one side of the outlet box and ungrounded conductor on the... -
Page 5: Unpacking Your Fan
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items: Set of blades (4) Mounting plate Blade Attachment Hardware 3/16"×9mm Allen Screws (17PCs.) Mounting bracket Light plate Rubber Washers (17PCs.) Fan motor assembly Glass shade Motor housing Transmitter+holder+2 mounting screws Electrical Hardware... -
Page 6: Installing Your Fan
Installing Your Fan Tools Required Figures 1 and 2 are examples of different ways to mount the outlet box. Phillips screwdriver, straight slot screwdriver, adjustable wrench, step ladder, and wire cutters. Outlet Box Mounting Options Outlet Box If there isn't an existing UL listed mounting box, then read the following instructions. -
Page 7: Making The Electrical Connections
Making the Electrical Hanging the Fan Connections REMEMBER to turn off the power. Follow the steps below to hang your fan properly. REMEMBER to disconnect the power. Attach the mounting bracket to the outlet box with two screws and washers provided with the If you feel you do not have enough electrical outlet box. - Page 8 After connecting the wires, spread them apart SUPPLY CIRCUIT so that the green and white wires are on one side of the outlet box and the black wires are on Frequency Switch the other side. Ground Conductor Turn the connecting nuts upward and push the wiring into the outlet box.
-
Page 9: Finishing The Fan Installation
Finishing the Fan Installation Move fan into position over the four mounting Screws Studs studs and secure with the provided washers and nuts. (Fig. 8) Raise the motor housing up against the Washers mounting bracket, the four supports inside the Nuts housing should be placed against the four studs on mounting bracket, twist the housing... -
Page 10: Attaching The Fan Blades
for measurement. Repeat for each blade. Attaching the Fan Blades Allen wrench Measurements deviation should be within 1/8˝. Run the fan for 10 Minutes. Attach the blade holder plate to the motor using the screws provided, tighten screws securely. Use the enclosed Blade Balancing Kit if the Allen Screws (Fig. -
Page 11: Installing The Light Kit
Installing the Light Kit Installing the Mounting Plate CAUTION BEFORE STARTING INSTALLATION, DISCON- Remove 1 of 3 screws from the mounting ring NECT THE POWER BY TURNING OFF THE and loosen the other 2 screws. (Do not remove) CIRCUIT BREAKER OR REMOVING THE FUSE AT FUSE BOX. -
Page 12: Operating Your Transmitter
Operating Your Transmitter Restore power to the ceiling fan and test for Installing the Battery: proper operation. Install 12V MN21/A23 battery (not included), to "HI, MED, LOW" buttons: prevent damage to transmitter, remove the battery These three buttons are used to set the fan if not used for long periods. - Page 13 NOTE TO OPERATE THE REVERSE FUNCTION ON THIS FAN, PRESS THE REVERSE BUTTON WHILE THE FAN IS RUNNING. Speed settings for warm or cool weather depend on factors such as the room size, ceiling height, number of fans, etc. Warm weather - (Counter-Clockwise direction) A downward air flow creates a cooling effect.(Fig.
-
Page 14: Care Of Your Fan
Make sure the dip switches are set correctly. Bay Ceiling Fan, please write to: WARNING THE HAMPTON BAY FAN & LIGHTING CO. MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX P. O. Box 395 BEFORE YOU ATTEMPY ANY REPAIRS. REFER TO THE SECTION, Norco, CA 92860 “MAKING ELECTRICAL CONNECTIONS”. -
Page 15: Specifications
Specifications FAN SIZE SPEED VOLTS AMPS WATTS N.W. G.W. C.F. 0.27 1584 9.20 kgs 10.80 kgs 44" MED. 0.36 2646 2.43 ' (20.30 lbs) (23.82 lbs) 0.44 4025 HIGH These are approximate measures. They do not include Amps and Wattage used by the light kit. Distributed by Your Other Warehouse, LLC 12100 Little Cayman Dr. -
Page 16: Warranty Information
Lifetime Limited Warranty (lifetime warranty on motor) The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time You must present a copy of the original purchase receipt to obtain warranty of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
