Status Indication; Table 7: Router Status Indication - Lucom UR5 v2 SL User Manual

5.7.1. Status indication

About router status inform eight led indicators on the front panel and on every port are
two LED indicators, which inform about port status.
Label Color
PWR Green
GSM Red
PPP Yellow
USR Yellow
OUT Green
IN Green
ETH Green
ETH Yellow
PORT Green
PORT Yellow
SIM1 Yellow
SIM2 Yellow

Table 7: Router status indication

State indicate of PPP LED is updated every 10 seconds.
11
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
State
Blinking Router is ready
On Starting of the router
Fast blinking Updating firmware
Blinking Communication in progress
1 x flash per Signal strength is from –50 dBm to –69 dBm
second
Signal strength is from –70 dBm to –89 dBm or difference
2 x flash per between neighbours cells is exactly 3 dBm
second
Signal strength is from –90 dBm to –113 dBm
3x flash per or difference between neighbours cells is smaller than
second 3 dBm
Function selected by user
On Binary output active
On Binary input active
On Selected 100 Mbit/s
Off Selected 10 Mbit/s
On The network cable is connected
Blinking Data transmission
Off The network cable is not connected
Description by port (viz. Technical specification of expansion port)
Description by port (viz. Technical specification of expansion port)
On SIM card 1 is active
On SIM card 2 is active
