5.8.1 Status indication
About router status inform four LED indicators on the front panel and on every port are two
LED indicators, which inform about port status.
Caption Color
PWR Green
USR Yellow
OUT Green
IN Green
ETH Green
ETH Yellow
PORT Green
PORT Yellow
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
State Description
Blinking Router is ready
On Starting of the router
Fast blinking Updating firmware
Function selected by user
On Binary output active
On Binary input active
On Selected 100 Mbit/s
Off Selected 10 Mbit/s
On The network cable is connected
Blinking Data transmission
Off The network cable is not connected
Depends on the expansion port (see user's guide of used port)
Depends on the expansion port (see user's guide of used port)
Table 5: Router status indication
