5.7.4. SIM card reader
The SIM card reader for 3 V and 1.8 V SIM cards is located on the front panel
of the router. To initiate the router into operation it is necessary to insert an activated SIM card
with unblocked PIN in the reader. The SIM cards might be of different adjusted APN (Access
Point Name).
Changing the SIM card:
Press the small yellow button to eject the reader holder. Insert the SIM card into
the reader holder and slide it in the reader (see figure bellow).
5.7.5. Ethernet port
Panel socket RJ45.
Pin
Signal mark
number
1
2
3
4
5
6
7
8
Table 9: Connection of Ethernet connector
ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible!
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Fig. 23: Ejected the SIM card
TXD+
Transmit Data – positive pole
TXD-
Transmit Data – negative pole
RXD+
Receive Data – positive pole
---
---
---
---
RXD-
Receive Data – negative pole
---
---
---
---
Fig. 24: Ethernet connector
ROUTER DESCRIPTION
